Nikon Z50 II setup guide with tips and tricks

Nikon Z50 II setup guide with tips and tricks

Introduction

The Nikon Z50 II camera is the
Þ
rst Nikon hybrid equipped with an APS-C
sensor. In a compact form factor, the Z50 II has the right to satisfy demanding
photographers: 20.9MP APS-C DX sensor with enhanced autofocus, subject detection autofocus with 3D tracking and nine subject types, Expeed 6
processor, 100-51200 Iso sensitivity, and oversampled 4K video at 30fps from 5.6K resolution.
.

Full Menu Overview and explanation

MENU
!
!
Playback Menu
!


Delete

Here you can:

• delete all pictures on the memory card
• choose pictures to be deleted in a thumbnail preview
• delete pictures by shooting date.

Note the hints at the bottom of the monitor that tells you which keys have to be used.
Hack:</
span>
!
The main advantage of this menu is the option to delete by
shooting date.

Playback Folder

If there are several folders on your memory card you can choose here from which
folders images will be displayed in playback mode:

• only from the one that is currently used for new pictures (as de
Þ
ned in the
shooting menu Storage Folder)
• from all folders, the Z50 II has created (default)
• from all folders on the memory card Ð possibly including pictures from other
sources.

Hack:</
span>
!
Ignore. I would not exchange memory cards between
cameras without formatting them to reduce the risk of write errors (=loss of
pictures!).
That makes the last option unattractive and I do not see practical use in using
several Storage Folders and consequently the other two choices.

Playback Display Options

You can add Focus point info to the playback display here as well as add additional
photo info like
!
Exposure Info,
!
Highlights, RGB Histogram,
!
Shooting Data…

Image Review

If turn this on, each new image will appear automatically on the monitor just after
shooting.
Hack:</
span>
!
I prefer to switch off this option because the regular
ß
ickering of the monitor is annoying if you leave the camera close to the eye.

After Delete

Hack:</
span>
!
I prefer the last option because I delete images both while
browsing forward or backward and then it is nice if the display adapts to the direction
you are using.

After Burst, Show

Rotate All

If you switch on this option photos taken in upright format will be rotated during a
preview.
If you switch on this option photos taken in upright format will be rotated during a
preview.

Slide Show

View a slide show of the pictures in the current playback folder.
!
Hidden images are
not displayed.
Options:

• Start:
!
Start slide show.
• Image type:
!
Choose the type of image displayed from
!
Still images and
movies,
!
Still images only, and
!
Movies only.
• Frame interval: Choose how long each picture will be displayed.
• Skip back/skip ahead:
!
Press
!
left
!
to return
to the previous frame, right
!
to skip to next frame.
• View additional photo info:
!
Press
!
up
!
or
down
!
to change or hide photo info displayed (still images only).
• Pause:
!
Press OK
!
to pause the slide show. To restart, highlight
!
Restart
!
and
press
!
OK.
• Adjust volume:
!
Press magni
Þ
er
!
during movie playback to increase volume,
mag+
ß
ash
!
to decrease.
• Exit to playback menu:
!
Press Menu
!
to end the slide show and return to the
playback menu.
• Exit to playback mode:
!
Press
!
Play
!
to end
the slide show and exit to playback mode.
• Exit to shooting mode:
!
Press shutter-release button halfway to return to
shooting mode.

Rating

Rate pictures or mark them as candidates for later deletion. Ratings can also be
viewed in ViewNX-i and Capture NX-D. Rating is not available with protected
images.
Procedure:

1. 1. Select an image:
!
Display the image or highlight it in the thumbnail list in
thumbnail playback.
   2. Display playback options.
!
Press the
!
info</
span>
!
button to display playback options.
   3. Select
!
Rating:
!
Highlight
!
Rating
!
and press right.

1. Choose a rating. Press
!
left
!
or
right
!
to choose a rating of from zero to
Þ
ve stars, or select
!
trash can
!
to mark the picture as a candidate for later deletion.
Press
!
OK
!
to complete the operation.

Hack:
!
If
!
Rating
!
is selected for Custom Setting f1 (Custom
control assignment) >
!
Fn2 button, pictures can be rated by keeping the
!
Fn2
!
button
pressed and pressing
!
left
!
or right.

MENU
!
!
Photo Shooting Menu
!

!
 page 1

Reset Photo Shooting Menu

This menu resets all entries in the shooting menu back to the default values de
Þ
ned
by Nikon, the only exception is the entry Storage Folder.
Hack:
!
This menu may be useful if you are new
to the Z50 II and have played a lot with the settings in this menu.

Storage Folder

This menu de
Þ
nes the folder on the memory card in which new images are stored
and allows to create new folders:

• Select folder by number:
!
You choose a three-digit number and the Z50 II will
create a folder with this number at the beginning of its name if it does not exist yet.
The following
Þ
ve characters ãZ50 IIÒ cannot be altered.
When you see a folder symbol next to the selected number a folder exists already.</
li>
• Select folder from the list:
!
You choose a folder from a list of existing ones Ð
without the possibility to create new ones.

File Naming

You can replace the three letters ãDSCÒ which are the default beginning of
Þ
le names
with your own individual combination.

• an underscore _ before or after these three letters, depending on which
color space you use.
• a sequential four-digit number.

Choose Image Area

The Nikon Z50 II offers a choice of the following image areas:

• DX (24
”
 16):
!
Images are recorded in DX format. To calculate the
approximate focal length of the lens in 35 mm format, multiply by 1.5.
• 1:1 (24
”
24):
!
Pictures are recorded with an aspect ratio of 1:1
• 16:9 (36×20):
!
Pictures are recorded with a 16:9 image ratio.

Image Quality

The Nikon Z50 II supports the following image quality options:

• NEF (RAW):
!
RAW data from the image sensor are saved without additional
processing. Settings such as white balance and contrast can be adjusted after
shooting.
• NEF (RAW)+JPEG
Þ
ne/NEF (RAW)+JPEG
Þ
ne:
!
Two images are recorded,
one NEF (RAW) image and one
Þ
ne-quality JPEG image.
• NEF (RAW)+JPEG
Þ
ne/NEF (RAW)+JPEG
Þ
ne:
!
Two images are recorded,
one NEF (RAW) image and one
Þ
ne-quality JPEG image.
• NEF (RAW)+JPEG normal/NEF (RAW)+JPEG normal:
!
Two images are
recorded, one NEF (RAW) image and one normal-quality JPEG image.
• NEF (RAW)+JPEG basic/NEF (RAW)+JPEG basic:
!
Two images are
recorded, one NEF (RAW) image and one basic-quality JPEG image.
• JPEG
Þ
ne/JPEG
Þ
ne:
!
Record JPEG images at a compression ratio of
roughly 1 : 4 (
Þ
ne quality).
• JPEG normal/JPEG normal:
!
Record JPEG images at a compression ratio of
roughly 1 : 8 (normal quality).
• JPEG basic/JPEG basic:
!
Record JPEG images at a compression ratio of
roughly 1 : 16 (basic quality).

Image Size

Image size is measured in pixels. Choose from
!
Large,
!
Medium, or
!
Small
!
(note that
image size varies depending on the option selected for
!
Image area.

DX (24
”
16; DX format)

• Large: 5568 x3712
• Medium: 4176 x 2784
• Small: 2784 x 1856

1 : 1 (24
”
24)

• Large: 3712 x 3712
• Medium: 2784 x 2784
• Small: 1856 x 1856

16 : 9 (36×20)

• Large: 4468 x 37128
• Medium: 4176 x 2344
• Small: 2784 x 1560

NEF (RAW) Recording

ISO sensitively settings

If the Nikon Z50 II decides that it can’t properly expose the image at that
!
ISO
!
given
your current aperture and shutter speed, it automatically adjusts
!
ISO
!
as necessary.
Turn on the Auto
!
ISO Sensitivity option.
!
The camera will now override your ISO
choice when it thinks a proper exposure is not possible with the settings youÕve
speci
Þ
ed.

If On is selected, the camera will automatically adjust ISO
sensitivity when optimal exposure cannot be achieved at the value selected for ISO
sensitivity. The options listed below are available for
Þ
ne-tuning auto ISO sensitivity
control.

• Maximum sensitivity: Choose an upper limit for ISO sensitivity to prevent it
from being raised too high.
• Maximum sensitivity with c: Choose the
upper ISO sensitivity limit for photos taken using an optional
ß
ash unit.
• Minimum shutter speed: Choose the shutter speed below which auto ISO
sensitivity control will kick in to prevent underexposure in modes P and A. Options
range from 1/4000 s to 30 s.

MENU
!
!
Photo Shooting Menu
!

!
 page 2

White Balance

White balance ensures that colors are unaffected by the color of the light source.
Auto white balance is recommended with most light sources. If the desired results
cannot be achieved with auto white balance, choose an option from the list below or
use preset white balance.

Auto

White balance is adjusted automatically for optimal results with most light sources.
For best results, use type G, E , D or Z lens. If optional
ß
ash
Þ
res, results are
adjusted appropriately. Color temperature can be viewed in the playback info display
after shooting.
Options:

• Keep white (reduce warm colors; 3500Ð8000 K)
• Normal
!
(3500Ð8000 K)
• Keep warm lighting colors(3500Ð8000 K)

Natural light auto

White balance is adjusted for natural light, producing colors closer to those seen by
the naked eye. (4500Ð8000 K)

Incandescent

Use under incandescent lighting. (3000K)

Fluorescent

• Sodium-vapor lamps
!
(2700 K):
!
Sodium-vapor lighting (found in sports
venues).
• Warm-white
ß
uorescent(3000 K):
!
Warm-white
ß
uorescent lights.
• White
ß
uorescent(3700 K):
!
White
ß
uorescent lights.
• Cool-white
ß
uorescent(4200 K):
!
Cool-white
ß
uorescent lights
• Day white
ß
uorescent(5000 K):
!
Daylight white
ß
uorescent lights.
• Daylight
ß
uorescent(6500 K):
!
Daylight
ß
uorescent lights.
• High temp. mercury-vapor
!
(7200 K):
!
High color temperature light sources
(e.g. mercury-vapor lamps).

Direct sunlight

Use with subjects lit by direct sunlight. (5200K)

Flash

Use with optional ßash units. (5400K)

Cloudy

Use in daylight under overcast skies. (6000 K)

Shade

Use in daylight with subjects in the shade. (8000 K)

Choose color temp.

Choose color temperature from list of values. (2500Ð10,000 K)

Preset manual

Use subject, light source, or existing photograph as reference for white balance.

Set Picture Control

Here you can change settings for the internal processing of picture data from the
image sensor into
Þ
nal JPG
Þ
les.
It’s necessary to start with an existing con
Þ
guration or
!
set of settings that Nikon has
prede
Þ
ned for a certain look of the
Þ
nal image. You can choose between:

• Standard:
!
NikonÔs default for a neutral picture as the standard for most
shooting situations.
• Neutral:
!
A processing with slightly less sharpening, contrast improvement,
and saturation; for those who do these steps on their own later on.
• Vivid:
!
Higher color saturation, sharpening, and contrast.
• Monochrome:
!
Converts into black and white.
• Portrait:
!
Very similar to ãneutralÒ, slightly less sharpening, contrast and color
saturation than ãstandardÒ.
• Landscape:
!
Higher contrast than ãstandardÒ.

You can modify any of these preset con
Þ
gurations by placing a yellow selection mark
in it and use the
!
selector to the right.
The ãQuick adjustÒ increases or decreases all settings in the direction of the intended
picture style and is available for all con
Þ
gurations except ãneutralÒ.
Alternatively, you can select and change all detail settings individually:

• Sharpening:
!
Increases contrasts at edges which improve the perceived
sharpness.
• Contrast:
!
Increases or decreases the contrast between light and dark
areas.
• Brightness:
!
Lightening or Darkening of the whole picture.
• Saturation:
!
Changes color saturation for more intense or fainter colors.
• Hue:
!
Changes the overall color tone in a slightly complicated manner.

And also two which are available only for the conÞguration ãmonochromeÒ:

• Filter effects:
!
Simulates the effect of color
Þ
lters as they are used in black
and white photography to adjust contrast.
• Toning:
!
Allows you to choose another dominating color tone than black and
white.

Additionally, you can create your own con
Þ
gurations by copying, modifying and
renaming an existing one.
To do so you need the next menu option Manage Picture Control.
When you change a conÞguration in the Picture Control and do a Reset
your last chosen conÞguration will stay selected but any changes in it will be reset.
Tips: An important menu with a visible impact on your photos! Only those who shoot
in RAW format only and create JPG
Þ
les on their own in the computer can ignore it.
The ãbestÒ settings are a matter of your personal preferences, in this menu, everyone
has to
Þ
nd his or her best settings by experience.
On the other hand, all of these settings can also be changed afterward in image
processing on the computer, you really have to get them right in the camera if you
want to have the best possible results straight out of your Nikon Z50 II.
The con
Þ
guration ãneutralÒ is very similar to ãstandardÒ with slightly less contrast and
saturation, the difference is really small.
The sharpening chosen by Nikon is rather weak, I prefer a higher value of 5 or 6.
When looking at your images in the proper magni
Þ
cation (100% zoom on the
computer monitor) you will see clearer edges.
ãVividÒ has visibly more intense color and more contrast. That can improve your
image but also be too much of a good thing if you have already high contrast (e.g.
direct sunlight) and make your picture look unnatural.
I would not set contrast and brightness here and switch on the Active D-Lighting.
Regarding the setting ãhueÒ: Ignore this setting, it is only a slight shift in color for
which I do not see any practical relevance.
Result: All the above has brought me to the following settings that I use myself:
One own con
Þ
guration, created with the next menu option Manage Picture Control,
called ãstandard+sharperÒ which is a copy of the con
Þ
guration ãstandardÒ with
sharpening increased to 6.
Another con
Þ
guration called ãsharp+vividÒ which is the same as before plus a
saturation increased by two steps.
I use the Þrst one most of the time and switch to the second one occasionally.
Last but not least: Do not overestimate the importance of this menu, most important
is still a good subject, light, exposure and
white balance for cooler or warmer color rendition. After all that the ãPicture
ControlÒ is for the
Þ
nal touch.

Manage Picture Control

This menu allows you to copy existing
!
Picture Control con
Þ
gurations (see the
previous menu) and save them with personal adjustments under a new name.
To create your own con
Þ
guration choose the entry ãSave/editÒ, pick an existing
con
Þ
guration and press OK. Then you can assign one of nine places in the list of
possible customized entries, edit it and choose your own name.
you do not really need your own con
Þ
guration and can ignore this menu. With the
user settings also personal adjustments to a Picture Control will be saved.
If you do change the Picture Control settings regularly it is best to put the most
commonly used settings into your own con
Þ
gurations.
Reset will put all Picture Control con
Þ
gurations back to their default settings and you
need an own con
Þ
guration if you do not want to tweak Picture Control each time with
your setting details.

• Save/edit:
!
Create a new custom Picture Control based on an existing preset
or custom Picture Control, or edit existing custom Picture Controls.
• Rename:
!
Rename custom Picture Controls.
• Delete:
!
Delete custom Picture Controls.
• Load/save:
!
Use the following options to copy custom Picture Controls to
and from the memory card. Once copied to the memory card, Picture Controls can
be used with other cameras or compatible software. (Copy to the camera,
!
Delete
from the card or Copy to the card.)

Color Space

You can either choose sRGB or Adobe RGB.

• sRGB
!
(default): This is the worldwide standard with 256 levels of brightness
for each of the basic colors red, green, blue, for displaying images on computer
monitors.
• Adobe RGB:
!
A color space developed by Adobe for a broader color range
of printed images.

As for sRGB, all colors will be stored with shares of red, green and blue with 256
levels of gradation, the difference is that the maximum saturations are higher.
The color space is relevant only for the creation of JPG-Þles, not for the RAW format.

Active D-Lighting

ãActive D-LightingÒ (ADL) is NikonÔs name for an additional step in the internal image
processing that mainly lightens dark areas of the picture.
It is relevant only for JPG Þles, not for the RAW format.
You can set this to Auto, Extra High, High, Normal, Low or Off.
ADL can also darken too bright areas but lightening dark ones are more frequent and
the improvements are more visible there.
You can choose an automatic adjustment that the Nikon Z50 II will set stronger or
weaker depending on your subjectÔs contrast or four steps from low to extra high.
Hack: Turn this ON, set it to
Normal, it really helps improve your images!

Long Exposure NR

If this menu option is switched on the Nikon Z50 II will use an extra step in internal
image processing for noise reduction if the exposure time is longer than 1 second.
Hack: switch it Off, it’s
better to use advanced image noise reduction on your Mac

High ISO NR

You can choose if an additional noise reduction shall be applied in the internal image
processing for shots with high ISO sensitivity.

Vignette Control

Vignetting is a drop in brightness at the edges of a photograph.
!
Vignette
control
!
reduces vignetting for type G, E, D and F lenses (PC lenses excluded). Its
effects vary from lens to lens and are most noticeable at maximum aperture. Choose
from
!
High,
!
Normal,
!
Low, and
!
Off.
Hack:
!
Depending on the
scene, shooting conditions, and type of lens, TIFF and JPEG images may exhibit
noise (fog) or variations in peripheral brightness, while custom Picture Controls and
preset Picture Controls that have been modi
Þ
ed from default settings may not
produce the desired effect. Take test shots and view the results in the monitor.
Vignette control does not apply to movies or multiple exposures.

MENU
!
!
Photo Shooting Menu
!

!
 page 3

Diffraction Compensation

With digital cameras, if you select a small aperture to increase depth of
Þ
eld when
shooting cityscapes or landscapes, it may cause a loss of sharpness across the
image due to diffraction.
!
.
Thanks to the new and faster EXPEED 6 processor inside the Nikon Z50 II, there is a
new
!
diffraction compensation function. This helps capture landscapes and
cityscapes crisply even when small apertures are used(from f/11 onwards).

Auto Distortion Control

Select
!
On
!
to reduce barrel distortion when shooting with wide-angle lenses and to
reduce pin-cushion distortion when shooting with long lenses (note that the edges of
the area visible in the view
Þ
nder may be cropped out of the
Þ
nal photograph and that
the time needed to process photographs before recording begins may increase).

Flicker Reduction Shooting

Reduce banding or (in photos taken in continuous release modes) uneven exposure
or coloration caused by the
ß
icker of such light sources as
ß
uorescent or mercury-
vapor lamps during view
Þ
nder photography.
Reduce banding or (in photos taken in continuous release modes) uneven exposure
or coloration caused by the
ß
icker of such light sources as
ß
uorescent or mercury-
vapor lamps during view
Þ
nder photography.
Hack:
!
Take a test shot and
view the results before taking additional photographs. Flicker reduction can detect
ß
icker at 100 and 120 Hz (associated respectively with AC power supplies of 50 and
60 Hz). Flicker may not be detected or the desired results may not be achieved with
dark backgrounds, bright light sources, or decorative lighting displays and another
non-standard lighting. Depending on the light source, there may be a slight delay
before the shutter is released. During burst shooting, the frame rate may slow or
become erratic; in addition, the desired results may not be achieved if the frequency
of the power supply changes during shooting.
Flicker detection will not take effect at shutter speeds slower than 1/100 s (including
Bulb and Time) or when
!
Mup
!
is selected for release mode or exposure delay mode is
on.

Metering

Metering determines how the camera sets exposure. The following options are
available:

1. Matrix: Produces natural results in most situations.
Camera meters wide area of the frame and sets exposure according to tone
distribution, color, composition, and, with type G, E, D or F lenses , distance
information (3D color matrix metering III; with other CPU lenses, camera uses color
matrix metering III, which does not include 3D distance information).
2. Center-weighted: Camera meters entire frame but
assigns greatest weight to center area (if CPU lens is attached, size of area can be
selected using Custom Setting b6,
!
Center-weighted area,
!
if non-CPU or AF-S
Fisheye NIKKOR 8Ð15mm f/3.5Ð4.5E ED lens is attached, area is equivalent to
circle 12 mm in diameter). Classic meter for portraits; recommended when using
Þ
lters with an exposure factor (
Þ
lter factor) over 1
”
.
3. Spot: Camera meters circle 4 mm (0.16 in.) in diameter
(approximately 1.5% of frame). The circle is centered on the current focus point,
making it possible to meter off-center subjects (if non-CPU or AF-S Fisheye NIKKOR
8Ð15mm f/3.5Ð4.5E ED lens is used or if auto-area AF is in effect, the camera will
meter center focus point). Ensures that the subject will be correctly exposed, even
when the background is much brighter or darker.
4. Highlight-weighted: Camera assigns the greatest weight
to highlights. Use to reduce the loss of detail in highlights, for example when
photographing spotlit performers on-stage.

Hack:
!
Specifying the focal
length and maximum aperture of non-CPU lenses using the
!
Non-CPU lens
data
!
option in the setup menu
!
allows the camera to use color matrix metering when
the matrix is selected and improves the accuracy of center-weighted and spot
metering.

Flash Control

Choose the
ß
ash control mode for optional
ß
ash units mounted on the camera
accessory shoe and adjust settings for off-camera
ß
ash photography.

Flash Control Mode

When an SB-5000, SB-500, SB-400, or SB-300 is mounted on the camera, the
ß
ash
control mode,
ß
ash level, and other
ß
ash settings can be adjusted using the
!
Flash
control
!
>
!
Flash control mode
!
item in the photo shooting menu (in the case of the
SB-5000, these settings can also be adjusted using the controls on the
ß
ash unit).
The options available vary with the
ß
ash used, while the options displayed
under
!
Flash control mode
!
vary with the mode selected. Settings for other
ß
ash units
can only be adjusted using
ß
ash unit controls.

• TTL: i-TTL mode. In the cases of the SB-500, SB-400, and SB-300,
ß
ash
compensation can be adjusted using the
!
W
!
(M) button.
• Auto external
ß
ash: In this mode, the output is adjusted automatically
according to the amount of light re
ß
ected by the subject;
ß
ash compensation is also
available. Auto external
ß
ash supports Òauto apertureÓ (q</
span>A) and Ònon-TTL autoÓ (A) modes; non-TTL auto is selected automatically if a
non-CPU lens is attached without specifying the focal length and maximum aperture
using the
!
Non-CPU lens data
!
option in the setup menu. See the
ß
ash unit manual for
details.
• Distance-priority manual: Choose the distance to the subject;
ß
ash output
will be adjusted automatically. Flash compensation is also available.
• Manual: Choose the
ß
ash level manually.
• Repeating
ß
ash: The
ß
ash
Þ
res repeatedly while the shutter is open,
producing a multiple-exposure effect. Choose the
ß
ash level (Output), the maximum
number of times the unit
Þ
res (Times), and the number of times the
ß
ash
Þ
res per
second (Frequency, measured in Hertz). The options available for
!
Times
!
vary
depending on the options selected for
!
Output
!
and
!
Frequency; see the documentation
provided with the
ß
ash unit for details.

Wireless Flash Options

Adjust settings for simultaneous wireless control of multiple remote
ß
ash units. This
option is available only when an SB-5000 or SB-500
ß
ash unit or a WR-R10 wireless
remote controller is mounted on the camera.

• Optical AWL:
!
The remote
ß
ash units are controlled using low-intensity
ß
ashes emitted by the master
ß
ash. Available only with an SB-5000 or SB-500
mounted on the camera accessory shoe.
• Optical/radio AWL:
!
This option is for
ß
ash photography using both optically-
and radio-controlled
ß
ash units. Choose this option when using both a WR-R10 and
an SB-500 mounted on the camera accessory shoe.
!
Remote
ß
ash control
!
is
automatically set to
!
Group
ß
ash.
• Radio AWL:
!
The remote
ß
ash units are controlled by radio signals emitted
by a WR-R10 attached to the camera. Available only with the WR-R10 and remote
ß
ash units that support radio AWL.
• Off:
!
Remote
ß
ash photography disabled.

Remote Flash Control

Choose from the following remote ßash photography options:

• Group
ß
ash:
!
hoose a separate
ß
ash control mode and
ß
ash level for each
group of remote
ß
ash units. If
!
Optical AWL
!
or
!
Optical/radio AWL
!
is selected
for
!
Wireless
ß
ash options you can choose the channel used by the master
ß
ash to
communicate with the remote
ß
ash units.
• Group
ß
ash:
!
hoose a separate
ß
ash control mode and
ß
ash level for each
group of remote
ß
ash units. If
!
Optical AWL
!
or
!
Optical/radio AWL
!
is selected
for
!
Wireless
ß
ash options you can choose the channel used by the master
ß
ash to
communicate with the remote
ß
ash units.
• Quick wireless control:
!
Choose for control of the overall
ß
ash output.
Use
!
Quick wireless control options
!
to adjust the balance between groups A and B
and set the output for group C manually (the master
ß
ash does not
Þ
re). You can
also adjust
ß
ash compensation for groups A and B and, if
!
Optical AWL
!
or
!
Optical/
radio AWL
!
is selected for
!
Wireless
ß
ash options
!!
choose the channel used by the
master
ß
ash to communicate with the remote
ß
ash units
• Remote repeating:
!
The
ß
ash units
Þ
re repeatedly while the shutter is open,
producing a multiple-exposure effect. Choose the
ß
ash level (Output), the maximum
number of times the
ß
ash units
Þ
re (Times), the number of times the units
Þ
re per
second (Frequency), and, if
!
Optical AWL
!
or
!
Optical/radio AWL
!
is selected
for
!
Wireless
ß
ash options, the channel used by the master
ß
ash to communicate with
the remote
ß
ash units. Note that the number of times the
ß
ash units
Þ
re in total may
vary depending on the options selected for
!
Output
!
and
!
Frequency; see the
documentation provided with the
ß
ash unit for details.

Radio Remote Flash Info</
h6>

Flash Mode

Some of the
ß
ash modes are set on the camera, rather than on the
ß
ash. To set most
of these modes on a Nikon Z50 II, you keep the
ß
ash button depressed and rotate the
main (rear) command wheel to cycle through the modes. The modes appear in the
ß
ash frame in the top LCD panel on the camera.
To set Auto FP on a Nikon Z50 II, you need to go into this menu.

Fill Flash

The
ß
ash
Þ
res with every shot. In modes P and A, the shutter speed will
automatically be set to values between 1/200 s (or 1/8000 s with Auto FP High-
Speed Sync) and 1/60 s.

Red-eye Reduction Mode

When this mode is activated (showed by an eye-symbol appearing on both the
camera’s top LCD and the
ß
ash’s rear LCD), the
ß
ash
Þ
res three
ß
ashes at reduced
output just before the picture is taken. This makes the iris of humans and animals
contract which reduces the area where the red-eye effect can be seen. It also
introduces a shutter delay to allow the subject’s irises time to react.
The red-effect only occurs when you use the
ß
ash as key light pointing forwards and
directly into the subject’s eyes.

Slow-sync Flash + red-eye

As for Red-eye reduction except that shutter speed slows automatically to capture
background lighting at night or under low light. Use when you want to include
background lighting in portraits. The use of a tripod is recommended to prevent
blurring caused by camera shake.
As for Red-eye reduction except that shutter speed slows automatically to capture
background lighting at night or under low light. Use when you want to include
background lighting in portraits. The use of a tripod is recommended to prevent
blurring caused by camera shake.

Slow-sync Flash

The default shutter speed when using
ß
ash is 1/60 second (you can change this
default on a Nikon Z50 II with custom setting #24). The
ß
ash will use a faster shutter
speed if the ambient light requires it, but will not normally go below 1/60 second in
the modes where the camera controls the shutter speed.
When slow-sync
ß
ash is activated (on a Z50 II, you set this by pressing the
ß
ash
button and turning the main command wheel until the word ÒSLOWÓ appears on the
camera’s top LCD), shutter speeds as low as 30 seconds may be used to obtain the
correct exposure for both the main subject in the foreground lit by the
ß
ash, and the
background, in low-light situations or at night.
For slow shutter speeds, you may need to use a tripod to avoid camera shake.
In the
!
Night Portrait
!
scene mode, slow-sync
ß
ash is automatically
activated.

Rear-curtain Sync

Normally the
ß
ash
Þ
res at the same time the shutter curtain opens (i.e. front curtain
sync). When the rear curtain is activated (indicated by the word ÒREARÓ on the
camera’s top LCD), the
ß
ash
Þ
res just before the shutter curtain closes.
Rear-curtain sync may be selected when one is shooting fast-moving subjects at
slow shutter speeds. With front curtain sync, unnatural-looking pictures can occur
because the blurred movement appears to be
!
in front
!
of the subject frozen by
the
ß
ash. Rear-curtain sync creates a picture in which the blur of a moving subject
(for example, the taillights of a speeding car) appears
!
behind
!
the frozen
subject.
Rear-curtain sync automatically enables slow-sync mode, since the only time you
should want to use rear sync, is when you also set slow shutter speed to capture
blurred movement.
Using rear curtain sync with shutter speeds
!
faster
!
than 1/30 second is not
recommended. Rear-curtain sync introduces a delay between the pre-
ß
ash and the
main
ß
ash lasting the length of the exposure. This delay gives most people just
enough time to react to the pre-
ß
ash. Using rear sync for portraits is a sure way to
make your subjects blink or squint.
Rear-curtain sync can not be combined with AWL, or with the FP or RPT modes.

Auto FP


(Focal Plane) is a sync mode that lets you synchronize
ß
ash with higher shutter
speeds than the camera’s normal maximum
ß
ash synchronization shutter speed
(often called Òx-sync speedÓ).
To use this mode on a Nikon Z50 II, you need to have a CLS-compatible
ß
ash unit
connected to the camera’s hot-shoe, and you must enable
!
Auto FP
!
on
the camera. Without having
!
Auto FP
!
enabled, the camera will not let you
set the shutter speed higher than the x-sync speed when you use a CLS-compatible
ß
ash. With
!
Auto FP
!
enabled, you can use any shutter speed.
In
!
FP
!
mode the
ß
ash will not
Þ
re once, but many times at an extremely
rapid rate (typically 50 kHz) which begins with the opening of front curtain of your
camera’s focal plane shutter and ends with the closing of the rear curtain. This
permits the correct exposure to be obtained as the traveling slit of a dual curtain
shutter passes over the sensor at high-speed.
Note that using
!
FP
!
reduces the maximum power of the
ß
ash. The only
way to have FP is to illuminate the focal plane curtain, which, depending on the
shutter speed, may cover a very large percentage of the focal plane. This means that
the higher the shutter speed is above the shutter’s x-sync speed, the smaller the
area of
Þ
lm that gets illuminated by each
ß
ash.
The table below shows approximately how much the maximum power expressed as
guide number GN is reduced when an SB-900 is used in
!
FP
!
mode on a
Nikon Z50 II. It has full power (GN 34, ISO 100/meter) at the X-sync speed (1/200
second), is reduced by -1 EV (half power) at 1/250 second, and then by another -1
EV for each doubling of shutter speed. At 1/4000 second it is reduced by -5 EV, or
1/32 of full power.

Using
!
FP
!
will reduce the effective GN of the
ß
ash when
you
!
exceed
!
the x-sync speed. However, it has no effect at speeds lower
than the x-sync. It does no harm to have
!
Auto FP
!
permanently enabled.
On a Nikon Speedlight, the
!
FP
!
mode can be activated in the following
ß
ash modes:
!
TTL, TTL BL, AA, M, and
!
GN. On the Nissin
Di866, the
!
FP
!
mode only works in
!
TTL
!
mode.
Note: The
!
FP
!
mode is mainly useful when you want to use large
apertures when doing
!

Þ
ll-
ß
ash
!
in bright daylight. The FP mode
does
!
not
!
help you freeze motion. Normal
ß
ash photography is very good
at freezing motion since a burst of electronic
ß
ash is so incredibly brief. When the
dominant light on a scene is a very short
ß
ash of light it is almost as if you used a
very high shutter speed in the thousandths of a second. However, when you use FP
mode
ß
ash, the
ß
ash unit pulses the light output over a
!
longer
!
period of
time in order to simulate a light being lit for the entire time the shutter travels across
the focal plane. Since the
ß
ash burst is no longer very short, it becomes more dif
Þ
cult
to freeze motion, even with high shutter speeds. And because the FP mode makes
you lose so much of the power of the
ß
ash, it is not very useful when you want the
ß
ash to be the dominant light. For high-speed
ß
ash photography, you instead
use
!
manual
!
mode and adjust the power ratio to make sure that the
ß
ash
burst is short enough to ÒfreezeÓ movement.

High-Speed Sync Without Auto FP mode

The Nikon Z50 II will sync with most
ß
ash units at any shutter speed (i.e. up to 1/4000
second). This is because these models use a CCD sensor that works as an
electronic shutter at high shutter speed. A conventional mechanical shutter is only
used at shutter speeds below 1/125 second.
For some reason, Nikon has put in a program limitation that will not let you set faster
shutter speed than 1/500 second in these models if you mount a
!!
ß
ash unit in the
camera’s hot-shoe. You can get around this limitation by taping over the two metal
contacts on the back of the Speedlight.

Flash Compensation

Flash compensation can be used to adjust the level of the master and remote
ß
ash
units by from
#
3 to +1 EV in steps of 1/3 EV. To choose a value for
ß
ash
compensation, press the magnifying
!
button and rotate the sub-command dial until
the desired value is displayed in the control panel.
Flash compensation can be used to adjust the level of the master and remote
ß
ash
units by from
#
3 to +1 EV in steps of 1/3 EV. To choose a value for
ß
ash
compensation, press the magnifying
!
button and rotate the sub-command dial until
the desired value is displayed in the control panel.
When the master
ß
ash or a remote
ß
ash is set to TTL or Auto
!
and
ß
ash
compensation to a value other than ±0.0, an
!
icon will be displayed in the control
panel and view
Þ
nder and the current value for
ß
ash compensation can be viewed by
pressing mag. Normal
ß
ash output can be restored by setting
ß
ash compensation to
±0.0. Flash compensation is not reset when the camera is turned off.

Release Mode

Choose the operation performed when the shutter-release button is pressed all the
way down.

• Single frame: The Nikon Z50 II takes one photograph each time the shutter-
release button is pressed.
• Continuous L: While the shutter-release button is held down, the camera
records 1Ð4 frames per second. The frame rate can be chosen by rotating the sub-
command dial when Continuous L is highlighted in the release-mode menu.
• Continuous H: While the shutter-release button is held down, the camera
records up to about 5 frames per second.
• Continuous H (extended): While the shutter-release button is held down,
the camera records up to about 11 frames per second. The built-in
ß
ash and optional
ß
ash units cannot be used. Flicker reduction has no effect.
• Self-timer: Take pictures with the self-timer.

MENU
!
!
Photo Shooting Menu
!

!
 page 4

Focus Mode

AF-S (single AF):

Designed for shooting stationary subjects, this mode locks focus when you depress
the shutter button halfway. (Think
!
S
!
for
!
still, stationary.)
!
In
AF-S mode, the camera insists on achieving focus before it releases the shutter.
If this behavior annoys you, open the Custom Setting menu, choose Autofocus, and
then choose AF-S Priority Selection. If you change the setting to Release, the picture
is then recorded when you fully depress the shutter button even if focus isnÕt yet
achieved.

AF-C (continuous AF):

Geared to capturing moving targets, AF-C mode adjusts focus as needed as long as
the shutter button is pressed halfway. (Think
!
C
!
for
!
continuous
motion.) Remember that a focus-adjustment occurs only if the subject moves
closer to or farther from the camera.
If the subject is moving but only shifts a short distance in a horizontal direction, no
adjustment is needed because the focusing distance remains the same.
If the subject is moving but only shifts a short distance in a horizontal direction, no
adjustment is needed because the focusing distance remains the same.

AF-F

The camera adjusts focus continuously in response to subject movement or changes
in composition. Focus locks when the shutter-release button is pressed halfway. This
option is only available in movie mode.

MF (Manual Focus)

To focus manually, adjust the lens focus ring until the image displayed on the clear
matte
Þ
eld in the view
Þ
nder is in focus. Photographs can be taken at any time, even
when the image is not in focus.
Hack:
!
To decide which
shutter-release option is right for you, consider whether youÕd rather have any shot,
even if itÕs out of focus, or capture only those that are in focus. I prefer the latter, so I
set both AF-S and AF-C modes to Focus. Why waste battery power, memory card
space, and inevitable time deleting out-of-focus pictures? Yes, if youÕre shooting
rapid action, you may miss a few shots waiting for the focus to occur Ñ but if theyÕre
going to be lousy shots, who cares? Sports shooters who
Þ
re off hundreds of shots
while covering an event, though, may want to unlock shutter release for both AF-C
and AF-S modes. Again, you may wind up with lots of wasted shots, but you increase
the odds that youÕll capture that split-second Òhighlight reelÓ moment.

AF Area Mode

Choose how the focus point for autofocus is selected.

• Pinpoint AF:
!
Use for pinpoint focus on a selected spot in the frame. This
option is only available when photo mode is selected and Single AF is chosen for
Focus mode. Focusing may be slower than with single-point AF.

• Single-point AF: Select the focus point; the camera will focus on the subject
in the selected focus point only. Use with stationary subjects.
!
the ability to limit point
selection to every other point
!
allows you to quickly use the joystick, or
touchscreen, to position the AF point.

• Dynamic-area AF:
!
The camera focuses on a point selected by the
user. If the subject brie
ß
y leaves the selected point, the camera will focus based on
information from surrounding focus points, letting you concentrate on composition in
shots of moving subjects. This option is only available when photo mode is selected
and Continuous AF is chosen for Focus mode.

• Wide-area AF (S) and (L):
!
As for Single-point AF except that wider focus
points are used. The focus points for Wide-area AF (L) are wider than those for
Wide-area AF (S).
• Auto-area AF:
!
The camera automatically detects the subject and selects the
focus area. At default settings, the camera gives priority to portrait subjects; if a
portrait subject is detected, the selected subject will be indicated by a yellow border
(if multiple faces are detected, you can choose your subject using the multi-selector).
Subject tracking can be activated by pressing the OK
button.

A word on Subject tracking:
When Auto-area AF is selected for AF-area mode, pressing OK enables focus tracking. The focus point will change to a targeting
reticule; position the reticule over the target and either press OK again or press the AF-ON
!
button to start tracking. The focus point
will track the selected subject as it moves through the frame (in the case of portrait
subjects, the focus will track the subjectÕs face). To end tracking, press OK a third time. To exit the subject-tracking mode, press the
magni
Þ
er/question
!
button.
A word on Quick Focus-Point Selection:
or quicker focus-point selection, choose Every other point for Custom Setting a5
(Focus points used) to use only a quarter of the available focus points (the number of
points available for Wide-area AF (L) does not change). If you prefer to use the sub-
selector for focus-point selection, you can choose the Select center focus point for
Custom Setting f2 (Custom control assignment)
!
> Sub-selector center to allow the
center of the sub-selector to be used to quickly select the center focus point.

The Touch Shutter:
!
</
strong>Touch controls can be used to focus and release the shutter. Touch the
display to focus and lift your
Þ
nger to release the shutter.

Tap the icon shown in the illustration to choose the operation performed by tapping
the display in shooting mode. Choose from the following options:

• Touch: Touch the display to position the
focus point and focus (autofocus only; the touch shutter cannot be used to focus in
manual focus mode). Focus locks while your
Þ
nger remains on the display; lift your
Þ
nger to release the shutter. Available only in photo mode.
• Touch AF: As above, except that lifting your
Þ
nger from the display does not release the shutter. If auto-area AF is selected for
AF-area mode, the camera will track the selected subject as it moves through the
frame; to switch to a different subject, tap it in the display.
• Off: Touch shutter disabled.

Optical VR

Enable or disable de optical vibration reduction function of your lens, if the lens has
this functionality.

Auto Bracketing

Vary exposure,
ß
ash level, Active D-Lighting (ADL), or white balance slightly with
each shot, ÒbracketingÓ the current value. Bracketing can be used in situations in
which getting the right settings is dif
Þ
cult and there is not time to check results and
adjust settings with each shot, or to experiment with different settings for the same
subject. The following options are available:

• Auto bracketing set: Choose the setting or settings bracketed when auto
bracketing is in effect. Choose AE &
ß
ash bracketing to perform both exposure
and
ß
ash-level bracketing, AE bracketing
!
to bracket only exposure, Flash bracketing
to perform only
ß
ash-level bracketing, WB bracketing
!
to perform white-balance
bracketing, or ADL bracketing to perform bracketing using Active D-Lighting.
• Auto bracketing set: Choose the setting or settings bracketed when auto
bracketing is in effect. Choose AE &
ß
ash bracketing to perform both exposure
and
ß
ash-level bracketing, AE bracketing
!
to bracket only exposure, Flash bracketing
to perform only
ß
ash-level bracketing, WB bracketing
!
to perform white-balance
bracketing, or ADL bracketing to perform bracketing using Active D-Lighting.
• Number of shots: Choose the number of shots in the bracketing
sequence.
• Increment: Choose the amount the selected settings vary with each shot
(ADL bracketing excluded).
• Amount: Choose how Active D-Lighting varies with each shot (ADL
bracketing only).

Multiple Exposure

Record two to ten NEF (RAW) exposures as a single photograph.
Multiple exposure mode

• On (series): Take a series of multiple exposures. Select
!
Off
!
to resume
normal shooting.
• On (single photo): Take one multiple exposure.
• Off: Exit without creating additional multiple exposures.

Number of shotsChoose the number of exposures that will be combined to form a
single photograph.Overlay mode

• Add: The exposures are overlaid without modi
Þ
cation; gain is not
adjusted.
• Average: Before the exposures are overlaid, the gain for each is divided by
the total number of exposures taken (gain for each exposure is set to 1/2 for 2
exposures, 1/3 for 3 exposures, etc).
• Lighten: The camera compares the pixels in each exposure and uses only
the brightest.

HDR (High Dynamic Range)

Used with high contrast subjects, High Dynamic Range (HDR) preserves details in
highlights and shadows by combining two shots taken at different exposures.

HDR mode:

• On (series): Take a series of HDR photographs. Select
!
Off
!
to resume
normal shooting.
• On (single photo): Take one HDR photograph.
• Off: Exit without taking additional HDR photographs.

Exposure differential:
!
Choose the difference in exposure between the two
shots that are combined to make an HDR photograph. Choose larger values for
high-contrast subjects, or select
!
Auto
!
to let the camera adjust the exposure
differential according to the scene.

Smoothing:
!
Choose how much to smooth the boundaries between the
shots that make up each HDR photograph.

Interval Timer Shooting

Take photographs at the selected interval until the speci
Þ
ed number of shots has
been recorded. Select a release mode other than self-timer (E) when using the interval timer.

• Start:
!
Start interval timer shooting, either after 3 s (Now
!
selected for
!
Choose
start day/time) or at a selected date and time (Choose day/time). Shooting will
continue at the selected interval until all shots have been taken.
• Choose start day/time:
!
Choose a start option. To start shooting immediately,
select
!
Now. To start shooting at a chosen date and time, select
!
Choose day/time.</
li>
• Interval:
!
Choose the interval (hours, minutes, and seconds) between
shots.
• Intervals
”
shots/interval:
!
Choose the number of intervals and the number of
shots per interval.
• Exposure smoothing:
!
Selecting
!
On
!
allows the camera to adjust exposure to
match previous shot in exposure modes other than
!
M
!
(note that exposure smoothing
only takes effect in mode
!
M
!
if auto ISO sensitivity control is on). Large changes in
subject brightness during shooting may result in apparent variations in exposure, in
which case it may be necessary to shorten the interval between shots.
• Silent photography:
!
Select
!
On
!
to silence the shutter during shooting.
• Interval priority:
!
Choose whether the camera gives priority to exposure time
or interval timing in exposure modes
!
P
!
and
!
A. Select
!
On
!
to ensure photos are taken
at the chosen interval,
!
Off
!
to ensure that photos are correctly exposed. If
!
On
!
is
selected, be sure the
!
Minimum shutter speed
!
chosen for
!
ISO sensitivity
settings
!!
>
!
Auto ISO sensitivity control
!
in the photo shooting menu is faster than
the interval. You should also focus using manual focus or, if you are using autofocus,
choose
!
Release
!
for Custom Setting a1 (AF-C priority selection) or Custom Setting a2
(AF-S priority selection)
!
according to whether
!
AF-C
!
or
!
AF-S
!
is selected.
• Starting storage folder:
!
Highlight either of the following options and
press
!
2
!
to select or deselect:
!
New folder: A new
folder is created for each new sequence or
!
Reset
Þ
le numbering: File numbering is
reset to 0001 whenever a new folder is created.

Time-Lapse Movie

The camera automatically takes photos at selected intervals to create a silent time-
lapse movie.

• Start:
!
Start time-lapse recording. Shooting starts after about 3 s and
continues at the selected interval for the selected shooting time.
• Interval:
!
Choose the interval between shots in minutes and seconds.
• Shooting time:
!
Choose the shooting time (hours and minutes).
• Exposure smoothing:
!
Selecting
!
On
!
smooths abrupt changes in exposure in
exposure modes other than
!
M
!
(note that exposure smoothing only takes effect in
mode
!
M
!
if auto ISO sensitivity control is on). Large changes in subject brightness
during shooting may result in apparent variations in exposure, in which case it may
be necessary to shorten the interval between shots.
• Silent photography:
!
Select
!
On
!
to silence the shutter during shooting.
• Image area:
!
Choose an image area for time-lapse recording. The options
are those for the
!
Image area
!
item in the movie shooting menu.
• Image area:
!
Choose an image area for time-lapse recording. The options
are those for the
!
Image area
!
item in the movie shooting menu.
• Frame size/frame rate:
!
Choose the frame size and rate for the
Þ
nal movie.
The options are those for the
!
Frame size/frame rate
!
item in the movie shooting
menu.
• Interval priority:
!
Choose whether the camera gives priority to exposure time
or interval timing in exposure modes
!
P
!
and
!
A. Select
!
On
!
to ensure frames are taken
at the chosen interval,
!
Off
!
to ensure that frames are correctly exposed. If
!
On
!
is
selected, be sure the
!
Minimum shutter speed
!
chosen for
!
ISO sensitivity
settings
!
>
!
Auto ISO sensitivity control
!
in the photo shooting menu is faster than
the interval. You should also focus using manual focus or, if you are using autofocus,
choose
!
Release
!
for Custom Setting a1 (AF-C priority selection,) or Custom Setting
a2 (AF-S priority selection) according to whether
!
AF-C
!
or
!
AF-S
!
is selected.

MENU
!
!
Photo Shooting Menu
!

!
 page 5

Silent Photography

Select On to reduce vibrations caused by the shutter when shooting landscapes and
other static subjects. Use of a tripod is recommended. The
ß
ash and long exposure
noise reduction are disabled, as are the electronic front-curtain shutter and beep
speaker, regardless of the options selected for Custom Setting d5 (Shutter type) and
for Beep options in the setup menu. In continuous release modes, the frame
advance rate will change.
Enabling silent photography changes the frame advance rates for continuous release
modes
!
and disables some features, including the
ß
ash, beep speaker, long exposure
noise reduction, and the electronic front-curtain shutter.
Although the noise of the mechanical shutter is muted, other sounds may still be
audible, for example during autofocus or if the Menu
or Play button is pressed when an option other than
Off is selected for Vibration reduction. During silent photography,
ß
icker, banding, or
distortion may be visible in the display and in the
Þ
nal picture under
ß
uorescent,
mercury vapor, or sodium lamps or with subjects that are in motion, particularly if the
camera is panned horizontally or an object moves horizontally at high speed through
the frame. Jagged edges, color fringing, moir”, and bright spots may
also appear. Bright regions or bands may appear in some areas of the frame with
ß
ashing signs and other intermittent light sources or if the subject is brie
ß
y
illuminated by a strobe or other bright, momentary light source.

MENU
!
!
Movie Shooting Menu
!

!
 page 1

Reset Movie Shooting Menu

In case of trouble or unexpected behaviour,
!
highlight
!
Yes
!
and press
!
OK
!
to restore movie shooting menu options to their default
values.

File Naming

Choose the three-letter pre
Þ
x used in naming the image
Þ
les in which movies are
stored. The default pre
Þ
x is ÒDSCÓ.
Choose the three-letter pre
Þ
x used in naming the image
Þ
les in which movies are
stored. The default pre
Þ
x is ÒDSCÓ.

Frame Size/Frame Rate

Choose the movie frame size (in pixels) and frame rate.

4K UHD (max 29 minutes 59 seconds recording time)

• 2160 30p: 3840
”
 2160 (4K UHD); 30p
!
144 Mbps
• 2160 25p: 3840
”
 2160 (4K UHD); 25p
!
144 Mbps
• 2160 24p: 3840
”
 2160 (4K UHD); 24p 144 Mbps

HD (max 29 minutes 59 seconds recording time)

• 1080 120p: 1920 x 1080 120p; 144 Mbps
• 1080 100p:
!
1920 x 1080 100p;
!
144 Mbps
• 1080 60p:
!
1920 x 1080 60p; 56 Mbps
• 1080 50p:
!
1920 x 1080 50p;
!
56 Mbps
•
!
1080 25p:
!
1920 x 1080 25p;
!
28 Mbps
•
!
1080 24p:
!
1920 x 1080 24p;
!
28 Mbps

Slow-Mo (max 3 minute recording time)

• 1080 30p x 4: 1920 x 1080; 30p x 4 (slow-mo) 36 Mbps
• 1080 25p x 4: 1920 x 1080; 25p x 4 (slow-mo) 36 Mbps
• 1080 24p x 4: 1920 x 1080; 24p x 5 (slow-mo) 29 Mbps

Movie Quality

You can choose from High quality and Normal.

Movie File Type

Choose the Þle format for movies from MOV and MP4.
Hack: MP4 is superior!

ISO Sensitivity Settings

You can adjust the following ISO sensitivity settings:

• Maximum sensitivity: Choose the upper limit for auto ISO sensitivity control
from values between ISO 200 and Hi 2. Auto ISO sensitivity control is used in
exposure modes
!
P,
!
S, and
!
Aand when
!
On
!
is selected for
!
Auto ISO control (mode
M)
!
in exposure mode
!
M.
• Auto ISO control (mode M): Select
!
On
!
for auto ISO sensitivity control in
exposure mode
!
M,
!
Off
!
to use the value selected for
!
ISO sensitivity (mode M).
• ISO sensitivity (mode M): Choose the ISO sensitivity for exposure
mode
!
M
!
from values between ISO 64 and Hi 2. Auto ISO sensitivity control is used in
other exposure modes.

Hack: At high ISO sensitivities, the camera
may have dif
Þ
culty focusing and noise (randomly-spaced bright pixels, fog, or lines)
may increase. This can be prevented by choosing a lower value for the ISO
Maximum sensitivity.

White Balance

Choose the white balance for movies (same choices as for the Photo Settings)

Set Picture Control

Choose a Picture Control for movies. You’ll also
Þ
nd the Creative Picture Control
settings here. You can
Þ
nd presets like Dream, Morning, Pop, Sunday, Sober,
Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink,
Charcoal, Graphite, Binary and Carbon. These can off course be edited too

MENU
!
!
Movie Shooting Menu
!

!
 page 2

Manage Picture Control

You can create custom Picture Controls here. (again same procedure as for photos)

Active D-Lighting

Preserve details in highlights and shadows, creating movies with natural contrast.
Select
!
Same as photo settings
!
to use the option currently selected for photos.
Options are Auto, Extra High, High, Normal, Low or Off.

High ISO NR

Reduce ÒnoiseÓ (what Nikon calls randomly-spaced bright pixels) in movies recorded
at high ISO sensitivities

Vignette Control

reduce shading or lens vignetting automatically using this function.

Diffraction Compensation

Same as for stills, the Nikon Z50 II can automatically reduce the loss of sharpness due
to diffraction when lenses are used with an aperture above f/11.

Auto Distortion Control

Automatically corrects for peripheral distortion (requires a lens with a CPU chip with
distortion control support.)

Flicker Reduction

Reduce
ß
icker and banding when shooting movies under
ß
uorescent or mercury-
vapor lighting. Choose Auto to allow the camera to automatically choose the correct
frequency, or manually match the frequency to that of the local AC power supply.
If Auto fails to produce the desired results and you are unsure as to the frequency of
the local power supply, test both the 50 and 60
!
Hz options and choose the one that
produces the best results. Flicker reduction may not produce the desired results if
the subject is very bright, in which case you should try choosing a smaller aperture
(higher f-number). To prevent
ß
icker, select mode M and choose a shutter speed
adapted to the frequency of the local power supply: 1/125 s, 1/60 s, or 1/30 s for 60
Hz; 1/100 s, 1/50 s, or 1/25 s for 50 Hz.

Metering

Metering determines how the camera sets exposure. The same options as in the
Photo Menu are available.

• Matrix metering:
!
The camera meters a wide area of the frame and sets
exposure according to tone distribution, color, composition, and distance for results
close to those seen by the naked eye.
• Center-weighted metering:
!
The camera meters the entire frame but assigns
the greatest weight to an area in the center of the frame, the size of which can be
chosen using Custom Setting b3 (Center-weighted area). This is the classic meter
for portraits and is also recommended when using
Þ
lters with an exposure factor
(
Þ
lter factor) over 1
”
.
• Spot metering:
!
The camera meters a
!
4
!
mm circle (equivalent to
approximately 1.5% of the frame) centered on the current focus point, making it
possible to meter off-center subjects (if auto-area AF is in effect, the camera will
instead meter the center focus point). Spot metering ensures that the subject will be
correctly exposed, even when the background is much brighter or darker.
• Highlight-weighted metering:
!
The camera assigns the greatest weight to
highlights. Use this option to reduce loss of detail in highlights, for example when
photographing spotlit performers on-stage.

MENU
!
!
Movie Shooting Menu
!

!
 page 3

Release Mode

Focus Mode

• AF-S:
!
For stationary subjects. Press the shutter-release button halfway to
focus. If the camera is able to focus, the focus point will be displayed in green; focus
will lock while the shutter-release button is pressed halfway. If the camera fails to
focus, the focus point will
ß
ash red. At default settings, the shutter can only be
released if the camera is able to focus (focus priority).
• AF-C:
!
For moving subjects. The camera focuses continuously while the
shutter-release button is pressed halfway; if the subject moves, the camera will
predict the
Þ
nal distance to the subject and adjust focus as necessary. At default
settings, the shutter can be released whether or not the subject is in focus (release
priority).
• AF-F:
!
The camera adjusts focus continuously in response to subject
movement or changes in composition. Focus locks when the shutter-release button
is pressed halfway. This option is only available in movie mode.
• Manual focus:
!
The shutter can be released whether or not the subject is in
focus.

AF-Area Mode

AF-area mode controls how the camera selects the focus-point for autofocus.

• Pinpoint AF:
!
Use for pinpoint focus on a selected spot in the frame. This
option is only available when photo mode is selected and Single AF is chosen for
Focus mode. Focusing may be slower than with single-point AF.
• Pinpoint AF:
!
Use for pinpoint focus on a selected spot in the frame. This
option is only available when photo mode is selected and Single AF is chosen for
Focus mode. Focusing may be slower than with single-point AF.
• Single-point AF:
!
The camera focuses on a point selected by the user. Use
with stationary subjects.
• Dynamic-area AF:
!
The camera focuses on a point selected by the user. If
the subject brie
ß
y leaves the selected point, the camera will focus based on
information from surrounding focus points, letting you concentrate on composition in
shots of moving subjects. This option is only available when photo mode is selected
and Continuous AF is chosen for Focus mode.
• Wide-area AF (S or L):
!
As for Single-point AF except that wider focus points
are used. The focus points for Wide-area AF (L) are wider than those for Wide-area
AF (S).
• Auto-area AF:
!
The camera automatically detects the subject and selects the
focus area. At default settings, the camera gives priority to portrait subjects; if a
portrait subject is detected, the selected subject will be indicated by a yellow border
(if multiple faces are detected, you can choose your subject using the multi
selector).
!
Subject tracking
!
can be activated by pressing the OK button.

Hack:
!
For quicker focus-point selection,
choose Every other point for Custom Setting a5 (Focus points used) to use only a
quarter of the available focus points (the number of points available for Wide-area AF
(L) does not change). If you prefer to use the sub-selector for focus-point selection,
you can choose Select center focus point for Custom Setting f2 (Custom control
assignment)
!
> Sub-selector center to allow the center of the sub-selector to be
used to quickly select the center focus point.

Subject Tracking</
strong>:
!
When Auto-area AF is selected for AF-area mode, pressing OK
!
enables
focus tracking. The focus point will change to a targeting reticule; position the reticule
over the target and either press OK again or press
the AF-ON
!
button to start tracking. The focus point will track the selected subject as
it moves through the frame (in the case of portrait subjects, focus will track the
subjectÕs face). To end tracking, press J a third time.
To exit subject-tracking mode, press the mag/question
!
button.

Optical VR

Identical to the Photo Menu again. Only needed when your lens does not have a VR
switch. If your lens does have a VR switch, turning it of will turn off both lens and
sensor stabilisation.

Electronic VR

Choose whether to enable electronic vibration reduction in movie mode.

Microphone Sensitivity

Turn the built-in or external microphones on or off or adjust microphone sensitivity.
Choose
!
Auto sensitivity
!
to adjust sensitivity automatically,
!
Microphone off
!
to turn
sound recording off; to select microphone sensitivity manually, select
!
Manual
sensitivity
!
and choose a sensitivity.

Attenuator

Select
!
Enable
!
to reduce microphone gain and prevent audio distortion when
recording movies in loud environments.

Frequency Response

If
!
S
!
Wide range
!
is selected, the built-in and external
microphones will respond to a wide range of frequencies, from music to the bustling
hum of a city street. Choose
!
T
!
Vocal range
!
to bring
out human voices.

MENU
!
!
Movie Shooting Menu
!

!
 page 4

Wind Noise Reduction

Select
!
On
!
to enable the low-cut
Þ
lter for the built-in microphone (optional stereo
microphones are unaffected), reducing noise produced by wind blowing over the
microphone (note that other sounds may also be affected). Wind-noise reduction for
optional stereo microphones that support this feature can be enabled or disabled
using microphone controls.

MENU
!
!
Custom Setting Menu
!

!
 page 1

Reset Custom Settings

Resets all Custom settings to the factory settings.

Autofocus Settings

a1 AF-C Priority Selection

When
!
AF-C
!
is selected for photography, this option controls whether photographs
can be taken whenever the shutter-release button is pressed (release priority</
em>) or only when the camera is in focus (focus priority).


• Release:
!
Photos can be taken whenever the shutter-release button is
pressed.
• Focus: Photos can be taken only when the camera is in focus.

Regardless of the option selected, focus will not lock when
!
AF-C
!
is selected for
autofocus mode. The camera will continue to adjust focus until the shutter is
released.

a2 Auto-area AF face/Eye detection

When photographing portrait subjectswith Auto-area AF, use Custom Setting a2
(Auto-area AF face/eye detection) to choose whether the camera detects both faces
and eyes (face/eye-detection AF) or only faces (face-detection AF). If Face and eye
detection on is selected and a portrait subject is detected, an amber border
indicating the focus point will appear around the subjectÕs face or, if the camera
detects the subjectÕs eyes, one or the other of their eyes (face/eye-detection AF).
Faces detected when Face detection on is selected are similarly indicated by an
amber border. If AF-S is selected for focus mode, or if the camera is shooting using
AF-S when AF-A is selected for focus mode, the focus point will turn green when the
camera focuses.
If more than one portrait subject or more than one eye is detected, left arrow and
right arrow icons will appear on the focus point, and you will be able to position the
focus point over a different face or eye by pressing LEFT or RIGHT cursor. If the
subject looks away after their face is detected, the focus point will move to track their
motion. During playback, you can zoom in on the face or eye used for focus by
pressing OK.
If more than one portrait subject or more than one eye is detected, left arrow and
right arrow icons will appear on the focus point, and you will be able to position the
focus point over a different face or eye by pressing LEFT or RIGHT cursor. If the
subject looks away after their face is detected, the focus point will move to track their
motion. During playback, you can zoom in on the face or eye used for focus by
pressing OK.

a3 Focus points used

a4 AF activation

Choose whether the shutter-release button can be used to focus (Shutter/AF-ON) or
if focus can only be adjusted using the AF-ON button or other controls to which AF-
ON has been assigned (AF-ON only).

a5 Focus Points wrap-around

Choose whether focus-point selection Òwraps aroundÓ from one edge of the
view
Þ
nder to another

• Wrap: Focus-point selection Òwraps aroundÓ from top to bottom, bottom to
top, right to left, and left to right, so that, for example, pressing
!
2
!
when a focus point at the right edge of the view
Þ
nder
display is highlighted (1)
!
selects the corresponding focus point at the left edge of the
display (2):
• No wrap:
!
The focus-point display is bounded by the outermost focus points
so that, for example, pressing
!
2
!
when a focus point
at the right edge of the display is selected has no effect.

a6 Focus Point options

a7 Low Light AF

Autofocus is achievable with the Nikon Z50 II down to -4EV provided low-light
autofocus is activated. only works in Single AF!!!
Choose On for more accurate focus under low-light conditions when AF-S is selected
for focus mode, but note that camera may require more time to focus. This option
takes effect only in photo mode when a setting other than Auto is chosen with the mode dial. While low-light AF is in effect,
ÒLow-lightÓ will appear in the display and the display refresh rate may drop.
Hack: This slows down autofocus for general
photography, so it should be disabled except for focussing in really low light.

a8 Built-In AF-Assist Illuminator

Choose whether the built-in AF-assist illuminator lights to assist the focus
operation when lighting is poor.

• On: The illuminator lights as required (AF-S focus mode only).
• Off: The illuminator does not light to assist the focus operation. The camera
may not be able to focus when lighting is poor.

The AF-assist illuminator has a range of about 1Ð3 m (3 ft 4 in.Ð9 ft 10 in.); when
using the illuminator, remove the lens hood. Do not obstruct the AF-assist illuminator
while it is lit.

Metering/Exposure Settings

b1 EV steps for exposure cntrl

Select the increments used when making adjustments to shutter speed, aperture,
and bracketing.

b2 Easy exposure compensation

This option controls whether the
!
plus/minus
!
button is
needed to set exposure compensation. If
!
On (Auto reset)
!
or
!
On
!
is selected, the 0 at
the center of the exposure display will
ß
ash even when exposure compensation is
set to ±0.
This option controls whether the
!
plus/minus
!
button is
needed to set exposure compensation. If
!
On (Auto reset)
!
or
!
On
!
is selected, the 0 at
the center of the exposure display will
ß
ash even when exposure compensation is
set to ±0.

• On (Auto reset):
!
Exposure compensation is set by rotating one of the
command dials (see note below). The setting selected using the command dial is
reset when the camera turns off or the standby timer expires (exposure
compensation settings selected using the
!
E
!
button
are not reset).
• On:
!
As above, except that the exposure compensation value selected using
the command dial is not reset when the camera turns off or the standby timer
expires.
• Off:
!
Exposure compensation is set by pressing the
!
E
!
button and rotating the main command dial.

b3 Center-weighted area

Choose the size of the area given the most weight in center-weighted metering. If a
non-CPU lens is attached, the size of the area is
Þ
xed at 12 mm.
Remember that the exposure compensation
!
icon is not displayed when exposure
Þ
ne-tuning is in effect. The only way to determine how much exposure has been
altered is to view the amount in the
Þ
ne-tuning menu.

b4 Fine-Tune optimal exposure

Use this option to
Þ
ne-tune the exposure value selected by the camera. Exposure
can be
Þ
ne-tuned separately for each metering method by from +1 to Ð1 EV in steps
of 1/6 EV.

Timers/AE Lock Settings

c1 Shutter-release button AE-L

Choose whether exposure locks when the shutter-release button is pressed.

• On (half press):
!
Pressing the shutter-release button halfway locks
exposure.
• On (burst mode):
!
Exposure only locks while the shutter-release button is
pressed all the way down.
• Off:
!
Pressing the shutter-release button does not lock exposure.

c2 Self-timer

Choose the length of the shutter release delay, the number of shots
taken, and the interval between shots in self-timer mode.

• Self-timer delay: Choose the length of the shutter-release delay.
• Number of shots: Press
!
1
!
and
!
3
!
to choose the number of shots taken each time the
shutter-release button is pressed.
• Interval between shots: Choose the interval between shots when
the
!
Number of shots
!
is more than 1.

c3 Power off delay

Choose how long the monitor remains on when no operations are performed during
playback (Playback; defaults to 10 seconds) and image review (Image review;
defaults to 4 seconds), when menus (Menus; defaults to 1 minute) or information
(Information display; defaults to 10 s) are displayed, or during live view and movie
recording (Live view; defaults to 10 minutes). Choose a shorter monitor-off delay for
longer battery life.
Choose how long the monitor remains on when no operations are performed during
playback (Playback; defaults to 10 seconds) and image review (Image review;
defaults to 4 seconds), when menus (Menus; defaults to 1 minute) or information
(Information display; defaults to 10 s) are displayed, or during live view and movie
recording (Live view; defaults to 10 minutes). Choose a shorter monitor-off delay for
longer battery life.

Shooting/display Settings

d1 CL mode shooting speed

Choose the frame advance rate for low-speed continuous release mode.

d2 Max. continuous release

he maximum number of shots that can be taken in a single burst
in continuous release modes can be set to any value between 1 and 200. Note that
regardless of the option selected, there is no limit to the number of photos that can
be taken in a single burst when a shutter speed of 4
!
s or slower is selected in mode
S or M.

Regardless of the option selected for Custom Setting d2, shooting will slow when the
memory buffer
Þ
lls.

d3 Exposure delay mode

In situations where the slightest camera movement can blur pictures, shutter release
can be delayed by from about 0.2 to 3 seconds after the shutter is engaged.

d4 Limit selectable image area

Choose the options available when image-area selection is assigned to the i menu or to the command dials and a camera control.
Highlight the desired options and press the
!
right arrow
!
</
span>to select or deselect. Press OK to save
changes when settings are complete.


d5 Limit selectable image area

DX: (24×16)
1:1: (16×16)
16:9 (24×14

d6 File number sequence

When a picture is taken, the camera names the
Þ
le by adding one to the last
Þ
le
number used. This option controls whether
Þ
le numbering continues from the last
number used when a new folder is created, the memory card is formatted, or a new
memory card is inserted in the camera.

• On:
!
When a new folder is created, the memory card formatted, or a new
memory card inserted in the camera,
Þ
le numbering continues from the last number
used or from the largest
Þ
le number in the current folder, whichever is higher. If a
photograph is taken when the current folder contains a photograph numbered 9999,
a new folder will be created automatically and
Þ
le numbering will begin again from
0001.
• Off:
!
File numbering is reset to 0001 when a new folder is created, the
memory card is formatted, or a new memory card is inserted in the camera. Note
that a new folder is created automatically if a picture is taken when the current folder
contains 5000 pictures.
• Reset: Same as for
!
On, except that the next picture taken is assigned a
Þ
le
number by adding one to the largest
Þ
le number in the current folder. If the folder is
empty,
Þ
le numbering is reset to 0001.

d7 Apply settings to live view

Choose On to preview how changes to such settings as white balance, Picture
Controls, and exposure compensation affect color and brightness in photo mode, or
select Off to adjust brightness and hue for ease of viewing (regardless of the option
selected, the effects of the aforementioned settings are always visible in movie
mode).

d8 Framing grid display

Choose
!
On
!
to display on-demand grid lines in the view
Þ
nder for reference when
composing photos.

d9 Peaking highlights

When focus peaking is enabled in manual focus mode, objects that are in focus are
indicated by colored outlines in the display. Choose the peaking level and outline
color.

• Peaking level: Choose from 3 (high sensitivity), 2 (standard), 1 (low
sensitivity), and Off; the higher the value, the greater the depth that will be shown as
being in focus.
• Peaking highlight color: Choose the highlight color.

d10 View all in continuous mode

Choose whether image review is available during burst shooting. If
!
Off
!
is selected,
not only the monitor but also the monitor backlight will turn off during exposures.

Bracketing/Flash Settings

e1 Flash Sync Speed

This option controls ßash sync speed.

• 1/250 s (Auto FP):
!
Auto FP high-speed sync is used when a compatible
ß
ash unit is attached. If other
ß
ash units are used, shutter speed is set to 1/250 s.
When the camera shows a shutter speed of 1/250 s in exposure mode
!
P
!
or
!
A, auto
FP high-speed sync will be activated if the actual shutter speed is faster than 1/250
s. If the
ß
ash unit supports auto FP high-speed sync, shutter speeds as fast as
1/8000 s can be selected by the camera (modes
!
P
!
and
!
A) or by the user
(modes
!
S
!
and
!
M).
• 1/250 sÐ1/60 s:
!
Flash sync speed set to selected value.

Hack:
!
Fixing Shutter Speed at the Flash Sync
Speed Limit: To
Þ
x shutter speed at the sync speed limit in shutter-priority auto or
manual exposure modes, select the next shutter speed after the slowest possible
shutter speed (30 sec ort longer). An X (
ß
ash sync indicator) will be displayed in the
view
Þ
nder and control panel together with the
ß
ash sync speed.

Hack: Auto FP High-Speed Sync:
!
Auto FP high-speed sync allows
the
ß
ash to be used at the highest shutter speed supported by the camera, making it
possible to choose the maximum aperture for reduced depth of
Þ
eld even when the
subject is backlit in bright sunlight. The information display
ß
ash mode indicator
shows ÒFPÓ when auto FP high-speed sync is active.

e2 Flash Shutter Speed

Choose the slowest shutter speed available when front- or rear-curtain sync or red-
eye reduction is used in mode P or A (regardless of the setting chosen, shutter
speeds can be as slow as 30 s in modes S and M or at
ß
ash settings of slow sync,
slow rear-curtain sync, or red-eye reduction with slow sync).
Choose the slowest shutter speed available when front- or rear-curtain sync or red-
eye reduction is used in mode P or A (regardless of the setting chosen, shutter
speeds can be as slow as 30 s in modes S and M or at
ß
ash settings of slow sync,
slow rear-curtain sync, or red-eye reduction with slow sync).

e3 Exposure comp. for ßash

Choose how the camera adjusts ßash level when exposure compensation is used.

• Entire frame:
!
Both
ß
ash level and exposure compensation are adjusted to
modify exposure over the entire frame.
• Background only:
!
Exposure compensation applies to background only.

e4 Auto ISO sensitivity control (with ßash)

Choose the reference used to set exposure when a
ß
ash is used with auto ISO
sensitivity control.

• Subject and background:
!
The camera takes both the main subject and
background lighting into account when adjusting ISO sensitivity.
• Subject only:
!
ISO sensitivity is adjusted only to ensure that the main subject
is correctly exposed.

e5 Bracketing order

At the default setting of
!
MTR > under > over, exposure,
ß
ash, and white
balance bracketing are performed in the following order: the unmodi
Þ
ed shot is taken
Þ
rst, followed by the shot with the lowest value, followed by the shot with the highest
value. If
!
Under > MTR > over
!
(plus to minus) is
selected, shooting will proceed in order from the lowest to the highest value. This
setting has no effect on ADL bracketing.

Controls Settings

f1 Customize i menu

Customise the appearance of the i Menu. What’s included and what not.
Split-Screen Display Zoom:
!
When assigned to the i
menu, Split-screen display zoom can be used to split the display into two boxes
showing separate areas of the frame side-by-side at a high zoom ratio. The positions
of the magni
Þ
ed areas are shown in the navigation window, making it easier to check
focus at two different locations when photographing a building or other wide object
situated at right angles to the camera.

f2 Custom control assignment

Choose the functions assigned to camera controls, whether used individually or in
combination with the command dials.

f3 Custom controls (playback)

AE-L/AF-L button and OK button.

f4 Customize command dials

This option controls the operation of the main and sub-command dials.

• Reverse rotation: Reverse the direction of rotation of the command dials for
selected operations. Highlight options and press right</
span> to select or deselect, and then press OK to
save changes and exit.

• Change main/sub: Choose the roles played by the command dials
for exposure and focus operations.

  Change main/sub: Choose the roles played by the command dials
for exposure and focus operations.

  • Exposure setting: If On is selected, the main command dial will control
aperture and the sub-command dial shutter speed. If On (Mode A) is selected, the
main command dial will be used to set aperture in mode A only.
  • Autofocus setting: This option applies to the control assigned Focus mode/
AF-area mode using Custom Setting f2 (Custom control assignment). If On is
selected, the focus mode can be chosen by keeping the control pressed and rotating
the sub-command dial, AF-area mode by keeping the AF-mode button pressed and
rotating the main command dial.
• Menus and playback: Select Off to use the multi selector for menus and
playback. If On or On (image review excluded) is selected, the main command dial
can be used to choose the picture displayed during full-frame playback and to
highlight thumbnails and menu items. The sub-command dial is used in full-frame
playback to skip forward or back according to the option selected for Sub-dial frame
advance and in thumbnail playback to page up or down. While menus are displayed,
rotating the sub-command dial right displays the sub-menu for the highlighted option,
while rotating it left displays the previous menu. To make a selection, press 2 or J. Select On (image
review excluded) to prevent the command dials from being used for playback during
image review.
• Sub-dial frame advance: When On or On (image review excluded) is
selected for Menus and playback, the sub-command dial can be rotated during full-
frame playback to select a folder, to skip forward or back 10 or 50 frames at a time,
or to skip to the next or previous protected picture, the next or previous photo, the
next or previous movie, or the next or previous picture with a selected rating (to
choose the rating, highlight Rating and press right).

f5 Release Button to use dial

Selecting Yes allows adjustments that are normally made by holding a button and
rotating a command dial to be made by rotating the command dial after the button is
released. This setting applies to the plus/minus, ISO, and timer
!
buttons and also to
controls to which the following roles have been assigned using Custom Settings f2 or
g2 (Custom control assignment): Choose image area, Image quality/size, White
balance, Set Picture Control, Active D-Lighting, Metering, Flash mode/compensation,
Focus mode/AF-area mode, Auto bracketing, Multiple exposure, HDR (high dynamic
range), Exposure delay mode, Shutter spd & aperture lock, Peaking highlights,
Choose non-CPU lens number, and Microphone sensitivity.

f6 Reverse indicators

If minus plus bar is selected, the exposure indicators in the control panel, view
Þ
nder,
and information display are displayed with negative values on the left and positive
values on the right. Selectplus minus bar to display positive values on the left and
negative values on the right.

Movie Settings

g1 Customize i Menu

Choose the functions assigned to camera controls, whether used individually or in
combination with the command dials, when you press i.

g2 Custom controls

Assign the custom controls for operation when in movie mode.
!
Power aperture is
available only in modes A and M. The display may
ß
icker while aperture is adjusted.

g3 AF Speed

Change the speed of the autofocus for movie mode.
!
o choose when the selected
option applies, highlight When to apply and press right. Choose from Always (the
selected option applies whenever the camera is in movie mode) and Only while
recording (the selected option applies only while recording is in progress; at other
times, the focus speed is Ò+5Ó, or in other words as fast possible).

g4 AF tracking sensitivity

Choose how quickly focus responds when your subject leaves the focus point or
something passes between the subject and the camera in movie mode. Choose from
values between 7 (Low) and 1 (High). The higher the value, the slower the response
and the less likely you are to lose focus on your original subject when something
passes between the subject and the camera. The lower the value, the quicker the
camera is to respond to the subject leaving the focus area by shifting focus to a new
subject in the same area.

g5 Highlight display

Choose whether shading is used to indicate highlights (bright areas of the frame)
and select the level of brightness needed to trigger the highlight display.

• Display pattern: To enable the highlight display, select Pattern 1 or Pattern
2.
• Highlight display threshold: Choose the brightness needed to trigger the
movie highlight display. The lower the value, the greater the range of brightnesses
that will be shown as highlights. If 255 is selected, the highlight display will show only
areas that are potentially overexposed.

MENU
!
!
Setup Menu
!

!
 page 1

Format Memory Card

To begin formatting, choose a memory card slot and select
!
Yes.
!
Note that
formatting permanently deletes all pictures and other data on the card in the selected
slot.
!
Before formatting, be sure to make backup copies as required.

Save User Settings

Frequently-used combinations of settings can be assigned to the U1, U2, and U3
positions on the mode dial.
Follow the steps below to save settings:

1. 1. Select a mode.


Rotate the mode dial to the desired mode.

1. 1. Adjust settings.


Choose a focus point and make the desired adjustments to
ß
exible program (mode
P), shutter speed (modes S and M), exposure and
ß
ash compensation, aperture
(modes A and M), and settings in the photo shooting, movie shooting, and Custom
Settings menus.

1. 1. Select Save user settings.


Highlight Save user settings in the setup menu and press 2.

1. 1. Select a position.


Highlight Save to U1, Save to U2, or Save to U3 and press 2.

1. Save user settings.


Highlight Save settings and press J to assign the
settings selected in Steps 1 and 2 to the mode dial position selected in Step 4.

Reset User Settings

Reset settings for U1, U2, and U3 to default values.

Language

Choose a language for camera menus and messages.

Time Zone And Date

Change time zones, set the camera clock, synchronize the clock with the clock on a
smart device, choose the date display order, and turn daylight saving time on or off.

• Time zone:
!
Choose a time zone. The camera clock is automatically set to
the time in the new time zone.
• Date and time:
!
Set the camera clock.
• Date format:
!
Choose the order in which the day, month, and year are
displayed.
• Daylight saving time:
!
Turn daylight saving time on or off. The camera clock
will automatically be advanced or set back one hour. The default setting is
!
Off.

Monitor Brightness

Press the up or down arrow
!
to adjust monitor brightness. Choose
higher values for increased brightness, lower values for reduced brightness.

Note that monitor brightness can only be adjusted when the monitor is the active
display; it cannot be adjusted in the Òview
Þ
nder onlyÓ monitor mode or when your eye
is to the view
Þ
nder.

ViewÞnder Brightness

Adjust view
Þ
nder brightness. If Auto is selected, view
Þ
nder brightness will be
adjusted automatically in response to lighting conditions; to adjust brightness
manually, select Manual and press up or down
!
(choose higher values for increased
brightness, lower values for reduced brightness). Note that view
Þ
nder brightness can
only be adjusted when the view
Þ
nder is the active display; it cannot be adjusted
when the view
Þ
nder is off or in the Òmonitor onlyÓ monitor mode.

ViewÞnder Color Balance

Use the multi selector to adjust view
Þ
nder color balance as described in Monitor
Color Balance.

MENU
!
!
Setup Menu
!

!
 page 2

Information Display

If
!
Auto
!
(AUTO) is selected, the color of the lettering in the information display will
automatically change from black to white or white to black to maintain contrast with
the background. To always use the same color lettering, select
!
Manual
!
and
choose
!
Dark on light
!
(B; black lettering) or
!
Light on dark
!
(W; white lettering). Monitor
brightness will automatically be adjusted for maximum contrast with the selected text
color.

AF Þne-tune

Fine-tune focus for up to 20 lens types. Use only as required; AF tuning is not
recommended in most situations and may interfere with normal focus. Auto
Þ
ne-
tuning is available in live view.
!
We recommend that you perform
Þ
ne-tuning at a
focus distance you use frequently; if you perform focus-tuning at a short focus
distance, for example, you may
Þ
nd it less effective at longer distances.

AF
Þ
ne-tune (On/Off): Choose On to turn AF tuning on, Off to
turn it off.

Image Dust Off ref Photo

This setting requires reference data for the Image Dust Off option in Capture NX-D
(for more information, refer to Capture NX-D online help). Image Dust Off cannot be
used with small or medium-sized NEF (RAW) images.
A lens with a focal length of at least 50 mm is recommended when recording Image
Dust Off reference data. When using a zoom lens, zoom all the way in.

Acquire dust off reference data.


Press the shutter-release button the rest of the way down to acquire Image Dust Off
reference data. The monitor turns off when the shutter-release button is pressed.

Image Comment

Add a comment to new photographs as they are taken. Comments
can be viewed as metadata in ViewNX-i or Capture NX-D. The comment is also
visible on the shooting data page in the photo information display. The following
options are available:

• Input comment: Input a comment as described in ÒText
EntryÓ.
!
Comments can be up to 36 characters long.
• Attach comment: Select this option to attach the comment to all subsequent
photographs.
!
Attach comment
!
can be turned on and off by highlighting it and
pressing
!
2. After choosing the desired setting,
press
!
OK
!
to exit.

Copyright Information

Add copyright information to new photographs as they are taken.
Copyright information is included in the shooting data shown in the photo information
display and can be viewed as metadata in ViewNX-i or in Capture NX-D. The
following options are available:

• • Artist: Enter a photographer name as described in ÒText
EntryÓ.
!
Photographer names can be up to 36 characters long.
  • Copyright: Enter the name of the copyright holder as described in ÒText
EntryÓ. Copyright holder names can be up to 54 characters long.
  • Attach copyright information: Select this option to attach copyright
information to all subsequent photographs.
!
Attach copyright information
!
can be
turned on and off by highlighting it and pressing
!
2.
After choosing the desired setting, press
!
J
!
to exit.</
li>

Beep Options

Choose the pitch and volume of the beep that sounds when:

• The self-timer is in operation
• Time-lapse recording ends
• The camera focuses in photo mode (AF-S selected for focus mode; Focus
selected for Custom Setting a2, AF-S priority selection; and Off selected for Silent
photography)
• The touch screen is used for keyboard entry

The Beep options menu contains the following items:

• Beep on/off: Turn the beep speaker on or off, or select Off (touch controls
only) to disable the beep during keyboard entry while enabling it for other
purposes.
• Volume: Adjust beep volume.
• Pitch: Choose the pitch of the beep from High and Low.

Touch Controls

Adjust monitor touch control settings.

• Enable/Disable Touch Controls:
!
Select
!
Disable
!
to prevent accidental use of
touch-screen controls, or
!
Playback only
!
to enable touch-screen controls in playback
mode only.
• Full-Frame Playback Flicks:
!
Choose the gesture used to display the next
image in full-frame playback: a
ß
ick from right to left or a
ß
ick from left to right.

Self-portrait Mode

MENU
!
!
Setup Menu
!

!
 page 3

HDMI

Adjust settings for connection to HDMI devices.
!
The camera can record video
directly to connected HDMI recorders. Some recorders will even start and stop
recording in response to camera controls. Use the HDMI
!
option in the setup menu to
adjust settings for HDMI output.

• Output Resolution: Choose the format for images output to the HDMI
device. If Auto is selected, the camera will automatically select the appropriate
format.

• Advanced: Adjust the settings below.

  • Output range: Auto is recommended in most situations. If the camera is
unable to determine the correct RGB video signal output range for the HDMI device,
you can choose Limited range for devices with an RGB video signal input range of
16 to 235 or Full range for devices with an RGB video signal input range of 0 to 255.
Choose Limited range if you notice a loss of detail in shadows, Full range if shadows
are Òwashed outÓ or too bright.
  • External recording control: Enabling external recording control allows
camera controls to be used to start and stop recording when the camera is
connected via HDMI to a third-party recorder that supports the Atomos Open
Protocol (Atomos SHOGUN, NINJA, or SUMO-series Monitor recorders). An icon will
be displayed in the camera monitor: A is displayed in
movie live view, while B is displayed during movie
recording. During recording, check the recorder and recorder display to ensure that
footage is being saved to the device (note that the footage output to the device may
be disrupted while external recording control is in effect). The camera display will
turn off automatically when the standby timer expires, ending HDMI output; when
recording movies to an external device, select Standby timer for Custom Setting c3
(Power off delay) and choose No limit or a time longer than the anticipated recording
time. See the manual provided with the recorder for more information on device
features and operation.
  • Output data depth: Choose from 8 bit and 10 bit.
  • N-Log setting: Select On (cannot record to card) to preserve details in
highlights and shadows and avoid over-saturated colors when recording movies.
Choose this option (available only when 10 bit is selected for Output data depth)
when recording footage that will later be color-corrected. The footage will be
recorded directly to the external device and cannot be saved to the camera memory
card. The ISO sensitivity settings > Maximum sensitivity and ISO sensitivity (Mode
M) options in the movie shooting menu can be set to values of from ISO 1600 to
25600 and ISO 800 to 25600, respectively.
  • View assist: Choose On for a live preview of video footage recorded with
On (cannot record to card) selected for N-Log setting. The colors in the preview will
differ from those of the
Þ
nal movie, but this has no effect on the footage actually
recorded.

HDMI Output:
HDMI output is not available at movie frame sizes of 1920
”
 1080 120p, 1920
”
 1080
100p, or 1920
”
 1080 slow-mo or when the camera is connected to a device running
SnapBridge or Camera Control Pro 2.
10-Bit Output Data Depth:

10 bit can be used only with compatible recorders. Regardless of
the display mode selected, the camera monitor will turn on and the view
Þ
nder will
remain blank. No photos can be taken; during movie recording, the following
additional restrictions apply when 3840
”
 2160 is selected for frame size:

• Movies are not recorded to memory cards inserted in the camera.
• Icons and characters in the monitor will display at low resolution.
• Selecting the DX image area reduces the angle of view to about 90%.

Zoom

Movies
Þ
lmed at a frame size of 3840
”
 2160 are displayed at a
size of 1920
”
 1080 when zoomed in.

Location Data display

Adjust settings for use when the camera is connected to a device that provides
location data, namely a GPS receiver or a smart device running the SnapBridge app
(for more information on SnapBridge, see the appÕs online help).

• Standby timer: If Enable is selected when a GPS receiver is connected, the
exposure meters will turn off automatically if no operations are performed for the
period speci
Þ
ed Custom Setting c3 (Power off delay)
!
> Standby timer, reducing
the drain on the battery.
• Position: View the location data supplied by the GPS receiver or smart
device (the items displayed vary with the source).
• Set clock from satellite: Select Yes to synchronize the camera clock with the
time reported by the GPS device.

Airplane Mode

Select
!
Enable
!
to disable the wireless features of Eye-Fi cards and Bluetooth and Wi-
Fi connections to smart devices. Connections to other devices using a wireless
transmitter can only be disabled by removing the transmitter from the camera.

Connect To Smart Device

Adjust settings for connection to smart devices.

• Start:
!
Follow on-screen instructions to connect to the smart device.
• Password protection:
!
Choose a password for smart device connections and
turn password protection on or off.

Use SnapBridge to control the camera remotely from a smart device and download
pictures from the camera.
!
SnapBridge is available free-of-charge from the Apple App
Store and on Google Play.

Connect To PC

If On is selected, new photos will automatically be uploaded to the PC.

Connecting via USB:


If the supplied USB cable is used to connect the camera to a computer running
ViewNX-i, you can copy pictures to the computer, where they can be viewed, edited,
and organized.

Installing ViewNX-i:

Download the ViewNX-i installer from the following website and
follow the on-screen instructions to complete installation (existing users should be
sure to download the latest version, as earlier versions may not support the camera).
An Internet connection is required. For system requirements and other information,
see the Nikon website for your region.

Copying
Pictures to the Computer

Connect the USB cable.


After turning the camera off and ensuring that a memory card is inserted, connect
the supplied USB cable.

Turn the camera on.


The Nikon Transfer 2 component of ViewNX-i will start (if a message is displayed
prompting you to choose a program, select Nikon Transfer 2).

Wireless Remote (ML-L7) Options

Adjust settings for optional WR-R10 wireless remote controllers and for optional
radio-controlled
ß
ash units that support Advanced Wireless Lighting.

LED Lamp:


Enable or disable the status LEDs on a WR-R10 wireless remote controller mounted
on the camera. For more information, see the documentation supplied with the
wireless remote controller.
Link Mode:
Choose a link mode for WR-R10 wireless remote controllers mounted on other
cameras or radio-controlled
ß
ash units that support Advanced Wireless Lighting. Be
sure that the same mode is selected for the other devices.

Pairing: To pair the camera with a WR-R10, mount the WR-
R10 on the camera and press the pairing button.

Regardless of the option selected for Link mode, signals from paired wireless remote
controllers will always be received by the WR-R10. Users of the WR-1 wireless
remote controller will need to select pairing as the WR-1 link mode.

Assign remote (WR) Fn Button

Choose the role played by the Fn button on optional wireless remote controllers.

Conformity Marking

View a selection of the standards with which the camera complies.

Energy saving

turn on the energy saving function.
MENU
!
!
Setup Menu
!

!
 page 4

Slot Empty Release Lock

Selecting
!
Enable release
!
allows the shutter to be released when no memory card is
inserted, although no pictures will be recorded (they will however be displayed in the
monitor in demo mode). If
!
Release locked
!
is selected, the shutter-release button is
only enabled when a memory card is inserted in the camera.

Reset All Settings

Reset all settings except Language and Time zone and date to their default values.
Copyright information and other user-generated entries are also reset. We
recommend that you save settings using the Save/load settings option in the setup
menu before performing a reset.

Firmware Version

View the current camera Þrmware version of your Nikon Z50 II and attached lens.
MENU
!
!
Retouch Menu
!

!
 page 1

NEF (RAW) Processing

Create JPEG copies of NEF (RAW) photographs. If you displayed the retouch menu
by pressing the
!
G
!
button, you can use this option to
copy multiple images.

1. 1. Select NEF (RAW) processing.


Highlight NEF (RAW) processing in the retouch menu and press 2.

1. 1. Choose how images are selected.

      Choose from the following options:

      • Select image(s): Select one or more images manually.
      • Select date: Create JPEG copies of all the NEF (RAW) images taken on
selected dates.
      • Select all images: Create JPEG copies of all the NEF (RAW) images on the
memory card (proceed to Step 4).

1. 1. Select photographs.


If you chose Select image(s) in Step 2, a picture selection dialog will be displayed
listing only NEF (RAW) images created with this camera. Highlight images using the
multi selector and press the W (Q) button to select or deselect; selected images are indicated by a
Licon. To view the highlighted image full screen,
press and hold the X button. Press J to proceed to Step 4 when your selection is complete.

      If you chose Select date in Step 2, a list of dates will be displayed. Highlight dates
using the multi selector and press 2 to select or
deselect. Press J to select all NEF (RAW) pictures
taken on the chosen dates and proceed to Step 4.

1. 1. Choose settings for the JPEG copies.


Adjust the settings listed below, or select Original to use the setting in effect when
the photograph was taken (the original settings are listed below the preview). Note
that exposure compensation can only be set to values between
#
2 and +2 EV.

      1	Image quality
      2	Image size
      3	White balance
      4	Exposure compensation
      5	Set Picture Control

      6	High ISO NR
      7	Color space
      8	Vignette control
      9	Active D-Lighting
      10	Diffraction compensation

2. Copy the photographs.


Highlight EXE and press J to create a JPEG copy of
the selected photograph (if multiple photos are selected, a con
Þ
rmation dialog will be
displayed; highlight Yes and press J to create JPEG
copies of the selected photos). To exit without copying the photographs, press the
Gbutton.

Trim

Create a cropped copy of the selected photograph. The selected photograph is
displayed with the selected crop shown in yellow; create a cropped copy as
described below.
Create a cropped copy of the selected photograph. The selected photograph is
displayed with the selected crop shown in yellow; create a cropped copy as
described below.

To reduce size of the crop: Press mag/
question button.

To increase size of the crop: Press magni
Þ
er.

To change the crop aspect ratio: Rotate the main command
dial.

To change the crop aspect ratio: Rotate the main command
dial.

To position the crop: Use the multi selector. Keep the multi
selector pressed to move the crop rapidly to the desired position.

Resize

Create small copies of selected photographs.

1. 1. Select Resize.


Highlight Resize in the N tab and press 2.

      2. Choose a size.


Highlight Choose size and press 2.


Highlight the desired size and press J.

1. 1. Choose pictures.


Highlight Select image(s) and press 2.


Highlight pictures and press W (Q) to select or deselect (to view the highlighted picture full screen,
press and hold the X button). Selected pictures are
marked by a 8 icon. Press J</
span> when the selection is complete. Note that photographs taken at an image-
area setting of 5 : 4 (30
”
24), 1 : 1 (24
”
24), or 16 : 9 (36
”
20) cannot be resized.


2. Save the resized copies.


A con
Þ
rmation dialog will be displayed. Highlight Yesand press J to save the resized copies.

D-Lighting

D-Lighting brightens shadows, making it ideal for dark or backlit photos.
D-Lighting brightens shadows, making it ideal for dark or backlit photographs.

Quick retouch

Create copies with enhanced saturation and contrast. D-Lighting is applied as
required to brighten dark or backlit subjects.

Red-Eye Correction

This option is used to correct Òred-eyeÓ caused by the
ß
ash, and is available only
with photographs taken using the
ß
ash. The photograph selected for red-eye
correction can be previewed in the edit display. Con
Þ
rm the effects of red-eye
correction and press OK
!
to create a copy. Note that red-eye correction may not
always produce the expected results and may in very rare circumstances be applied
to portions of the image that are not affected by red-eye; check the preview
thoroughly before proceeding.
This option is used to correct Òred-eyeÓ caused by the
ß
ash, and is available only
with photographs taken using the
ß
ash. The photograph selected for red-eye
correction can be previewed in the edit display. Con
Þ
rm the effects of red-eye
correction and press OK
!
to create a copy. Note that red-eye correction may not
always produce the expected results and may in very rare circumstances be applied
to portions of the image that are not affected by red-eye; check the preview
thoroughly before proceeding.

Straighten

Create a straightened copy of the selected image. Press
!
2
!
to rotate the image clockwise by up to
Þ
ve degrees in
increments of approximately 0.25 degrees,
!
4
!
to
rotate it counterclockwise (the effect can be previewed in the edit display; note that
edges of the image will be trimmed to create a square copy). Press
!
OK
!
to save the retouched copy.

Distortion Control

Create copies with reduced peripheral distortion. Select
!
Auto
!
to let the camera
correct distortion automatically and then make
Þ
ne adjustments using the multi
selector, or select
!
Manual
!
to reduce distortion manually. Note that
!
Auto
!
is not
available with photos taken using auto distortion control; see ÒAuto Distortion
ControlÓ. Press
!
2
!
to reduce barrel distortion,
!
4
!
to reduce pincushion distortion (the effect can be
previewed in the edit display; note that greater amounts of distortion control result in
more of the edges being cropped out). Press
!
J
!
to
save the retouched copy. Note that distortion control may heavily crop or distort the
edges of copies created from photographs taken with DX lenses at image areas
other than
!
DX (24
”
16).

MENU
!
!
Retouch Menu
!

!
 page 2

Perspective Control

Image Overlay

Image overlay combines two existing NEF (RAW) photographs to create a single
picture that is saved separately from the originals; the results, which make use of
RAW data from the camera image sensor, are noticeably better than photographs
combined in an imaging application. The new picture is saved at current image
quality and size settings; before creating an overlay, set image quality and size.
!
To
create a NEF (RAW) copy, choose an image quality of
!
NEF (RAW)
!
and an image
size of
!
Large
!
(the overlay will be saved as a large NEF/RAW image even
if
!
Small
!
or
!
Medium
!
is selected).

1. 1. Select Image overlay.


Highlight Image overlay in the retouch menu and press 2</
span>. Image overlay options will be displayed, with Image 1highlighted; press
J to display a picture selection dialog listing only
large NEF (RAW) images created with this camera (small and medium NEF/RAW
images cannot be selected).


1. 1. Select the Þrst image.


Use the multi selector to highlight the
Þ
rst photograph in the overlay. To view the
highlighted photograph full frame, press and hold the mag</
span> button. Press OK to select the highlighted
photograph and return to the preview display.


1. 1. Select the second image.


The selected image will appear as Image 1. Highlight Image 2 and press OK, then
select the second photo as described in Step 2.

1. 1. Adjust gain.


Highlight Image 1 or Image 2 and optimize exposure for the overlay by pressing
1 or 3 to select
the gain from values between 0.1 and 2.0. Repeat for the second image. The default
value is 1.0; select 0.5 to halve gain or 2.0 to double it. The effects of gain are visible
in the Preview column.
      Highlight Image 1 or Image 2 and optimize exposure for the overlay by pressing
1 or 3 to select
the gain from values between 0.1 and 2.0. Repeat for the second image. The default
value is 1.0; select 0.5 to halve gain or 2.0 to double it. The effects of gain are visible
in the Preview column.

1. 1. Preview the overlay.


To preview the composition, press 4 or 2 to place the cursor in the Preview column, then press
up
!
or down to highlight Overlay and press OK (note that colors and brightness in the preview may
differ from the
Þ
nal image). To save the overlay without displaying a preview, select
Save. To return to Step 4 and select new photos or adjust gain, press mag/question button.

2. Save the overlay.


Press OK while the preview is displayed to save the
overlay. After an overlay is created, the resulting image will be displayed full-frame.

Trim Movie

Create a copy from which unwanted footage has been removed.

Choose Start/End Point</
h6>
Follow the steps below to create trimmed copies of movies.

1. 1. Display a movie full frame.

1. 1. Pause the movie on the new opening frame.


Play the movie back as described in ÒViewing MoviesÓ, pressing OK to start and resume playback and down to pause, and pressing left
!
or right or rotating the main or sub-command dial to locate
the desired frame. Your approximate position in the movie can be ascertained from
the movie progress bar. Pause playback when you reach the new opening frame.

      Movie progress bar

1. 1. Select Choose start/end point.


Press the i button to display the i menu, then highlight Choose start/end point and press OK.

1. 1. Select Start point.


To create a copy that begins from the current frame, highlight Start point and press
OK. The frames before the current frame will be
removed when you save the copy in Step 9.
      To create a copy that begins from the current frame, highlight Start point and press
OK. The frames before the current frame will be
removed when you save the copy in Step 9.

      Start point

1. 1. ConÞrm the new start point.


If the desired frame is not currently displayed, press 4</
span>or 2 to advance or rewind (to skip to 10 s
ahead or back, rotate the main command dial; to skip to the
Þ
rst or last frame, rotate
the sub-command dial).


1. 1. Choose the end point.


Press the center of the sub-selector to switch from the start point (w) to the end point (x) selection tool
and then select the closing frame as described in Step 5. The frames after the
selected frame will be removed when you save the copy in Step 9.

      Sub-selector

      End point

1. 1. Create the copy.


Once the desired frame is displayed, press 1.

1. 1. Preview the movie.


To preview the copy, highlight Preview and press OK
(to interrupt the preview and return to the save options menu, press 1). To abandon the current copy and select a new start
point or end point as described above, highlight Cancel and press J; to save the copy, proceed to Step 9.

2. Save the copy.


Highlight Save as new
Þ
le and press J to save the
copy to a new
Þ
le. To replace the original movie
Þ
le with the edited copy, highlight
Overwrite existing
Þ
le and press OK.

Trim Movie

Create a copy from which unwanted footage has been removed.

MENU
!
 My Menu

T
he
!
MY MENU
!
option can be used to create and edit a customized
list of options from the playback, photo shooting, movie shooting, Custom Settings,
setup, and retouch menus for quick access (up to 20 items). If desired, recent
settings can be displayed in place of My Menu.

Add Items

Add items to My Menu

Rewove Items

Remove Items from my menu.

Rank Items

change the ranking of your added items.

Choose Tab

Choose a tab for your added item.

The i Menu

The most used functions in the main Menu can also be easily accessed by pressing
the “I” on the back plate of the camera. This will bring you too the i Menu. This menu
is completely customisable for both Photo and Movie mode
!
(</
strong>Controls Settings
!
f1 – Customize i menu). We’ll have a quick look at the
functionality added to this Menu as factory settings.
Here you can change settings for the internal processing of picture data from the
image sensor into
Þ
nal JPG
Þ
les.
It’s necessary to start with an existing con
Þ
guration or
!
set of settings that Nikon has
prede
Þ
ned for a certain look of the
Þ
nal image. You can choose between:


• Auto: Your Nikon Z50 II automatically detects the type of scene.
• Standard:
!
NikonÔs default for a neutral picture as the standard for most
shooting situations.
• Neutral:
!
A processing with slightly less sharpening, contrast improvement
and saturation; for those who do these steps on their own later on.
• Vivid:
!
Higher color saturation, sharpening and contrast.
• Monochrome:
!
Converts into black and white.
• Portrait:
!
Very similar to ãneutralÒ, slightly less sharpening, contrast and color
saturation than ãstandardÒ.
• Landscape:
!
Higher contrast than ãstandardÒ.

You can also choose between a range of
!
picture presets like Dream, Morning, Pop,
Sunday, Sober, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia,
Blue, Red, Pink, Charcoal, Graphite, Binary and Carbon.

Image Quality

• NEF (RAW):
!
RAW data from the image sensor are saved without additional
processing. Settings such as white balance and contrast can be adjusted after
shooting.
• NEF (RAW)+JPEG
Þ
ne/NEF (RAW)+JPEG
Þ
ne:
!
Two images are recorded,
one NEF (RAW) image and one
Þ
ne-quality JPEG image.
• NEF (RAW)+JPEG normal/NEF (RAW)+JPEG normal:
!
Two images are
recorded, one NEF (RAW) image and one normal-quality JPEG image.
• NEF (RAW)+JPEG basic/NEF (RAW)+JPEG basic:
!
Two images are
recorded, one NEF (RAW) image and one basic-quality JPEG image.
• JPEG
Þ
ne/JPEG
Þ
ne:
!
Record JPEG images at a compression ratio of
roughly 1 : 4 (
Þ
ne quality).
• JPEG normal/JPEG normal:
!
Record JPEG images at a compression ratio of
roughly 1 : 8 (normal quality).
• JPEG basic/JPEG basic:
!
Record JPEG images at a compression ratio of
roughly 1 : 16 (basic quality).
• TIFF (RGB):
!
Record uncompressed TIFF-RGB images at a bit depth of 8
bits per channel (24-bit color). TIFF is supported by a wide variety of imaging
applications.

Flash Control

Choose the
ß
ash control mode for optional
ß
ash units mounted on the camera
accessory shoe and adjust settings for off-camera
ß
ash photography. See the
ß
ash
control settings in the menu for more info.

WiFi connection

Turn On/Off the WiFi connection.

Release Mode

• Single frame: The camera takes one photograph each time the shutter-
release button is pressed.
• Continuous low speed: While shutter-release button is held down, camera
takes photographs at frame rate selected for Custom Setting d1 (CL mode shooting
speed)
• Continuous high speed: While shutter-release button is held down, camera
takes photographs at frame rate given in ÒPower Source and Frame RateÓ Use for
active subjects.
• Continuous high speed plus: only with jpeg.
• Self-timer: Take pictures with the self-timer.

AF Area Mode

Choose how the focus point for autofocus is selected.

• Pinpoint AF:
!
Use for pinpoint focus on a selected spot in the frame. This
option is only available when photo mode is selected and Single AF is chosen for
Focus mode. Focusing may be slower than with single-point AF.
• Single-point AF: Select the focus point; the camera will focus on the subject
in the selected focus point only. Use with stationary subjects.
!
the ability to limit point
selection to every other point
!
allows you to quickly use the joystick, or
touchscreen, to position the AF point.
• Dynamic-area AF:
!
The camera focuses on a point selected by the user. If
the subject brie
ß
y leaves the selected point, the camera will focus based on
information from surrounding focus points, letting you concentrate on composition in
shots of moving subjects. This option is only available when photo mode is selected
and Continuous AF is chosen for Focus mode.
• Wide-area AF (S) and (L):
!
As for Single-point AF except that wider focus
points are used. The focus points for Wide-area AF (L) are wider than those for
Wide-area AF (S).
• Wide-area AF (S) and (L):
!
As for Single-point AF except that wider focus
points are used. The focus points for Wide-area AF (L) are wider than those for
Wide-area AF (S).
• Auto-area AF:
!
The camera automatically detects the subject and selects the
focus area. At default settings, the camera gives priority to portrait subjects; if a
portrait subject is detected, the selected subject will be indicated by a yellow border
(if multiple faces are detected, you can choose your subject using the multi selector).
Subject tracking
!
can be activated by pressing the OK</
span> button.

Image Size

Image size is measured in pixels. Choose from
!
Large,
!
Medium, or
!
Small
!
(note that
image size varies depending on the option selected for
!
Image area.

White Balance

White balance ensures that colors are unaffected by the color of the light source.
Auto white balance is recommended with most light sources. If the desired results
cannot be achieved with auto white balance, choose an option from the list below or
use preset white balance.

Metering

Metering determines how the camera sets exposure. The following options are
available:

• Matrix metering:
!
The camera meters a wide area of the frame and sets
exposure according to tone distribution, color, composition, and distance for results
close to those seen by the naked eye.
• Center-weighted metering:
!
The camera meters the entire frame but assigns
the greatest weight to an area in the center of the frame, the size of which can be
chosen using Custom Setting b3 (Center-weighted area). This is the classic meter
for portraits and is also recommended when using
Þ
lters with an exposure factor
(
Þ
lter factor) over 1
”
.
• Spot metering:
!
The camera meters a
!
4
!
mm circle (equivalent to
approximately 1.5% of the frame) centered on the current focus point, making it
possible to meter off-center subjects (if auto-area AF is in effect, the camera will
instead meter the center focus point). Spot metering ensures that the subject will be
correctly exposed, even when the background is much brighter or darker.
• Highlight-weighted metering:
!
The camera assigns the greatest weight to
highlights. Use this option to reduce loss of detail in highlights, for example when
photographing spotlit performers on-stage.

Face Tracking

Turn on face tracking, or automatic face detection and autofocus tracking.

Vibration Reduction

The Nikon Z50 II is equipped with in-camera vibration reduction (VR), other
manufacturers call this sensor stabilisation. The VR unit provides compensation for
movement along
Þ
ve axes. The effects of vibration reduction are equivalent to a
shutter speed up to approximately 5.0 stops. This function can also be used
effectively with NIKKOR F lenses, including those not equipped with a VR function,
with the Mount Adapter FTZ . ).
There is an ON (normal) and SPT (Sport) preset.

Focus Mode

1. AF-S:
!
For stationary subjects. Press the shutter-release button halfway to
focus. If the camera is able to focus, the focus point will be displayed in green; focus
will lock while the shutter-release button is pressed halfway. If the camera fails to
focus, the focus point will
ß
ash red. At default settings, the shutter can only be
released if the camera is able to focus (focus priority).
2. AF-C:
!
For moving subjects. The camera focuses continuously while the
shutter-release button is pressed halfway; if the subject moves, the camera will
predict the
Þ
nal distance to the subject and adjust focus as necessary. At default
settings, the shutter can be released whether or not the subject is in focus (release
priority).
3. AF-F:
!
The camera adjusts focus continuously in response to subject
movement or changes in composition. Focus locks when the shutter-release button
is pressed halfway. This option is only available in movie mode.
4. Manual focus:
!
The shutter can be released whether or not the subject is in
focus.

Quick how-to Nikon Z50 II settings

How to set-up back button focussing

Back button focussing is a focussing and composition method where you disconnect
the autofocus engine from the standard shutter button half-press. This enables you
to engage the autofocus system only with the AF-ON button on the backplate.

Now your autofocus and shutter are disconnected, enabling you to acquire autofocus
independently from the shutter button action. This method is often used to
recompose your shot after autofocus is acquired, the so-called focus and recompose
method.
This is very easy the set up with the Nikon Z50 II:

Conclusion

There is always a learning curve with every new camera you purchase. Luckily,
Nikon decided to keep the hierarchy and the logic of their DSLR series cameras in
the new Nikon Z50 II. This makes art easier to navigate at least for photographers
experienced with those cameras. The Nikon Z50 II is fairly new so I’ll add more tips
and tricks to this post as I get more and more familiar with it. If you have any
comments or questions, or just want to write about your experience with the Z50 II,
!
feel free to post them in the comment section below.
There is always a learning curve with every new camera you purchase. Luckily,
Nikon decided to keep the hierarchy and the logic of their DSLR series cameras in
the new Nikon Z50 II. This makes art easier to navigate at least for photographers
experienced with those cameras. The Nikon Z50 II is fairly new so I’ll add more tips
and tricks to this post as I get more and more familiar with it. If you have any
comments or questions, or just want to write about your experience with the Z50 II,
!
feel free to post them in the comment section below.
